Features
1. Double IGBT Module technology and PWM control, high quality and superior performances.2. Digital display, accurate current control, stable arc transition and excellent welding chaaracteristics.
3. Adjustable wire feeding speed, tip ball removing and electronic induction regulating.
4. Effective spatter control, improved penetration and better welding effect. Thermal overload protection.
5. Separated welder and the wire feeder; suitable for welding at high places or special position.
6. Wide range of working material, such as low carbon steel, low alloy steel, etc.
Technical Specifications
ITEM
| UNIT
| MIG-280
| MIG-350
| MIG-500
|
Input Power Voltage
| V
| AC380V±10%
| AC380V±10%
| AC380V±10%
|
Input Power Frequency
| Hz
| 50/60
| 50/60
| 50/60
|
Rated Input Capacity
| KVA
| 9.4
| 14
| 25
|
Output Current Range
| A
| 50-270
| 50-350
| 50-500
|
Load Voltage
| V
| 16.5-27.5
| 16.5-31.5
| 16.5-39
|
Rated Duty Cycle
| %
| 60
| 60
| 60
|
Wire Feed Speed
| M/min
| 3-15
| 3-15
| 3-15
|
Gas Flow
| L/min
| 15-20
| 15-20
| 15-20
|
Dimensions
| MM
| 500*235*400
| 500*235*400
| 550*270*450
|
weight
| Kg
| 18
| 20
| 25
|
Related products
Company Introduction
Certifications
Exhibition
Action now
Why choose Retop?
a. We are welding machine MANUFACTURER, so we can offer better price and after-sale service and shorter delivery date.
b. We use all new components,mosfet tube, diode, capacitor and so on imported components.
c. We adopt IGBT technology to decrease failure rate and it is convenient to repair the welding machine and reduce the cost of
repairing, we just need to change the bad pcb board.
d. We provide Warranty period of 1 year for all our items
