Used High Quality Trinity Concrete Pump Truck Mercedes-Benz Concrete Pump Truck Volvo Concrete Pump Truck 37 Meters 42 Meters 49 Meters 52 Meters Concrete

Product Description

Product Description

2011years, 37meters Mercedes-Benz Trinity concrete sky pump truck, fine condition, high efficiency
Technical parameter:

Technical Data
Model
Item	Unit	JH30-M	JH38-RZ	JH48-XR
Max.theoretical output	m3/h	90	140	180
Max.concrete outlet pressure	MPa	10.5	8.3	8.3
Rated working pressur	MPa	32	32	32
Hydraulic system	/	Open circuit	Open circuit	Open circuit
Pumping frequency	min-1	26	29	29
Concrete cylinder dia x stroke	mm	230X1450	230X1650	260X2100
Rotating angle of turret	•	±360	±360	±360
Max.concrete placing (height/radius/depth)	/	30/26/18.3	38/33/21.2	48/42/29.3
Chassis Mode	/	FAW/SINOTRUK
Max.powe	HP	180~340		300~420
Emission standards		EURO 5/EURO 6

Model
Item	Unit	JH52-XR	JH58-XR	JH62-XR	JH70-XR
Max.theoretical output	m3/h	180	180	180	180
Max.concrete outlet pressure	MPa	8.3	8.3	8.3	8.3
Rated working pressure	MPa	32	32	32	32
Hydraulic system	/	Open circuit	Open circuit	Open circuit	Open circuit
Pumping frequency	min-1	29	29	29	29
Concrete cylinder dia x stroke	mm	260X2100	260X2100	260X2100	260X2200
Rotating angle of turret	•	±360	±360	±360	±360
Max.concrete placing (height/radius/depth)	/	52/47/36.8	56/51/36.6	62/58.6/43	70/66/51
Chassis Model	/	FAW/SINOTRUK/FOTON/SHACMAN
Max.power	HP	300-420	420~550
Emission standards		EURO 5/EURO 6

FAQ;
1:What are your main products?A:Concrete pump truck,concrete pump,concrete line pump,concrete mixer truck,truck-mounted concrete pump,concrete batching plant,concrete pump spare parts
2: What items were repaired?A: We changed concreye pump truck glasses plate,cutting ring, all weaing parts and etc.
3: How do I know the condition of the concrete pump truck?A: We will provide a video of the test machine of the pump truck. Before we ship to you, we will test the machine for pumping for 8 hours.
4: What is the minimum order quantity for your concrete pump truck?A: The MOQ is 1 unit.
5. How can you guarantee quality? A: Our raw material every node will be inspected strictly.advanced equipment rather than only worker is been applied during the whole producing process to ensure the welding quality.Ensure that each of our customers is satisfied with the pump truck

---
