| US$2,150.00 | 1 Piece (MOQ) |
| Model | JFQ7-20W | JFQ7-30W |
| Laser source model | MFP-20X/20QS | MFP-30X/30QS |
| Output Power | 18.5W | 30W |
| Beam quality M2 | ≤1.4 | ≤1.4 |
| Pulse repetition frequency | 27-60 kHz | 30-60 kHz |
| Laser wavelength | 1064±5 nm | |
| Output power stability | <3% | |
| Working life | About 100,000 working hours (non-lifetime) | |
| Marking range | 100~150mm (range optional) | |
| Engraving depth | ≤1mm (depending on power and time) | |
| Engraving speed | ≤10000mm/s | |
| Repeat accuracy | ±0.002 | |
| Minimum marking line width | 0. 1mm | |
| Minimum character height | 0.15mm | |
| Cooling way | Built-in air cooling | |
| System power supply | 500W / 220V / 50Hz (110V can be connected) | |
| Temperature humidity | 0~40°, 30% RH 85%, air conditioner should be installed when used outside the range | |
| Oil mist, condensation | Not allowed | |
| Support system | Windows | |
| Dimensions | 460X300X683mm | |
| Packing size | 550X440X690 mm | |
| Total Weight | About 25kg | |
