Used High-Speed Vertical/Horizontal Cooling Ribbon Mixer New PVC Hot and Cold Mixer

Product Description

Uses and Features
1. It is used in mixing, drying, colouring and other processing. It is the most ideal equipment for producing shaped plastic
material and plastics pipes. 2. The technology of the mainshaft sealed apparatus and it has two functions of electric and steam heating.
3. Two layers of sealing technology is adopted in the pot cover. The opening of the heating mixed cover adopted the
airopening device and the opening of the cooling mixed cover adopted hydraulic pressure control system.
4. The electric control section with the programmable logic control adopted well-known imported meters and control components.
5. It could be equipped with the dust removing device.
6. The blades have been passed the test of the dynamic and static balance testing machine.
7.Manual feeding, vaccum feeding or screw feeding is available.
Mixer Unit SHR

Total volume(L)	Effective volume(L)	Rotating Speed (r/min)	Motor power (kw)
100	75	650/1300	14/22
200	150	475/950	30/42
300	225	475/950	40/55
500	375	430/860	55/75
800	600	357/714	83/110
1000	750	325/650	110/160
1500	1100	250/500	160/220

---
