Three Axies 250CNC Precision Machine Tool for Grinding and Milling Tasks

Product Description

250/2550CNC Surface Grinding MachineThree Axies 250CNC Multifunction Grinding Machine Tool
Driven by our unwavering commitment to excellence, we adhere to a policy of ceaseless advancement concerning all our products. We reserve the privilege to amend specifications, mechanics, or designs at any juncture, without prior notification or obligation.

	parameter	unit	CNC-250	CNC-2550
general picture	Table size (x*y)	mm	200×500	250*500
	X axis travel	mm	580	580
	Y axis travel	mm	230	280
	Max center of wheel to table	mm	380	380
	Maximum load	kg	200	200
Table	Table T cell specification	mm×N	14×1	14×1
	Table speed	m/min	0-25	0-25
Y axis	Minimum feed	mm	0.001	0.001
	Single feed		0.1~10	0.1~10
	Fast moving speed	mm/min	0~1200	0~1200
Z axis	Minimum feed	mm	0.001/0.01	0.001/0.01
	Fast moving speed	mm/min	0~800	0~800
grinding	grinding wheel size max	mm	Φ200×Φ31.75×19
	grinding wheel speed	R.P.M	0~3600	0~3600
motor	spindle motor	HXP	2×2	2×2
	the Z axis motor	W	750	750
	the Y axis motor	W	750	750
	the X axis motor	W	1500	1500
	cooling motor	W	90	90
Size	height of machine	mm	2000	2000
	floor space	mm	2000×1350	2000×1450
	weight(about)	kg	1450	1550

Cheng Yu Machinery Technology Co., Ltd., proudly established in the industrious city of Dongguan, Guangdong Province, boasts a prestigious 30-year legacy of grinding machine manufacturing, enriched by an accumulation of advanced technology from Taiwan and a team of skilled professionals. In the realm of CNC machine tools, the industry is experiencing swift progress, with the evolution towards high-speed, precision, composite functionalities, intelligent systems, open frameworks, parallel drive, connectivity, and eco-friendly solutions emerging as the pivotal trends steering future innovations. Dongguan Chengyu Machinery Technology Co., Ltd. stands as a paragon in the realm of machine tool production and processing. Our enterprise thrives on the tenets of 'technology, innovation, and reliability,' embracing a 'meticulous' quality policy to deliver top-tier products and unparalleled customer service. We meticulously analyze customer processes, technological needs, production types, and quality demands to refine our product development, pushing the boundaries of the numerical control industry. Our product offerings are characterized by high automation, precision, and quality, underpinned by an exemplary and scientific quality management system, cutting-edge equipment, and extraordinary technical expertise. In a proactive response to burgeoning market demands, Chengyu Machinery excels in the crafting and innovation of high-precision CNC surface grinding machines, CNC forming machines, four-axis punch grinders, vertical slider grinders, and gantry rail grinders. Our expertise also extends to the design and creation of industrial robots, automated production lines, and their seamless integration. Below is a concise overview of our CNC grinding machine series products: I. HS Series 618 / 250 / 3060 / 4080 / 40100 (available in both servo and hydraulic configurations) Processing Capacities: Offers surface grinding and grooving capabilities. It features a patented hydraulic control system (hydraulic model) for optimized performance. Functionality: Equipped with a comprehensive grinding program facilitating flat surface and groove cutting tasks. Feed Options: Selectable feed modes including front, back, left, and right, with memory functionality for each grinding program. Intelligent System: Includes grinding wheel overload protection with an automatic shutdown feature for enhanced safety. II. (servo type / hydraulic type) Processing Capacities: Tailored for surface grinding, grooving, and combined scheduling operations. Incorporates our patented hydraulic control system (hydraulic model) for superior performance. Functionality: Offers an array of grinding programs including surface grinding, groove cutting, sole grinding, side grinding, and variable distance/depth displacement grinding. Grinding Wheel Dressing: Facilitates bottom plane dressing with set rough/fine grinding timings and quantities, ensuring automatic dressing and compensation during grinding cycles. Feed Options: Front, back, left, and right selectable feed modes with memory capability for each grinding program, enhancing operational flexibility. Specialized Grooving: Supports equidistant and variable distance grooving tasks. 3. Our four-axis CNC grinding machines are available in both horizontal and vertical models. Processing Types: Capable of arbitrary equal division and skipping tooth processing for diverse applications. Features waist circle processing by inputting AB size parameters. Triangle Fillet Processing: Input inscribed circle size B and fillet size R for precision outcomes. Quadrilateral Fillet Processing: Input side lengths A and B alongside fillet size R for customized results. Eccentric Circle Functionality: Input eccentricity and diameters for precise start and end operations. To begin your machining journey, simply enter the starting and ending diameters for the circle, ensuring precision at every step. Unlock the full potential of arc creation by entering the desired arc size and perfectly calibrating the rotation angle for flawless execution. Achieve perfect precision with ease, whether working on step differences, rotation profiles, or other intricate tasks. Streamline your workflow by saving the processing schedule as a convenient file, ensuring quick and easy access for future use.

---
