| US$30,000.00 | 1 Piece (MOQ) |
| Model: | DGCF14/12/5 | DGCF18/18/6 | DGCF24/24/8 | DGCF32/32/10 | DGCF40/40/12 | |
| Production Capacity: 500ml(b/h) | 2000-3000 | 4000-5000 | 6000-7000 | 9000-10000 | 12000-15000 | |
| Filling precision | ≤5mm (liquid level) | |||||
| Filling pressure(Mpa) | <0.4 | |||||
| Suitable bottle standard:(mm) | Bottle diameter: φ40-φ80, bottle height: 130-280mm | Bottle diameter: φ50-φ100 bottle height: 150-320mm | ||||
| Suitable cap standard:(mm) | Plastic screw cap, φ50-φ110 | |||||
| Pressure for washing bottle(Mpa) | 0.18-0.25 | |||||
| Water consumption for washing bottle(Kg/h) | 1300 | 2000 | 2500 | 3000 | 3600 | |
| Spraying position | 5 | 5 | 6 | 12 | 15 | |
| Dripping bottle position | 2.5 | 3.0 | 3.5 | 7 | 9 | |
| Gas source pressure(Mpa) | 0.4 | |||||
| Gas consumption (m3/min) | 0.3 | 0.4 | 0.4 | 0.5 | 0.6 | |
| Total power(Kw) | 5.03 | 5.03 | 6.57 | 8.07 | 10.07 | |
| Overall Dimension (L×W×H, mm) | 2100×1500×2200 | 2450×1800×2200 | 2750×2180×2200 | 3600×2200×2600 | 4300×2300×2750 | |
| Total Weight:(kg) | 2000 | 3500 | 5500 | 8000 | 9500 | |
