CRG2512-FZ-R500E-1 Bourns Current Sense Resistors - SMD ResMetalStrip 2512 R500 1% 1W TCR50 AEC-Q200

Product Details

Product Description

Product Description
Factory
Mfr. #:
CRG2512-FZ-R500E-1
Manufacturer: Bourns
Product Category: Current Sense Resistors - SMD
RoHS: Details
Series: CRG2512
Resistance: 500 mOhms
Power Rating: 3 W
Tolerance: 1 %
Temperature Coefficient: 50 PPM / C
Case Code - in: 2512
Case Code - mm: 6432
Minimum Operating Temperature: - 55 C
Maximum Operating Temperature: + 170 C
Technology: Metal Strip
Termination: 2 Terminal
Termination Style: SMD/SMT
Qualification: AEC-Q200
Packaging: Reel
Packaging: Cut Tape
Packaging: KXXReel
Application: Current Sense
Brand: Bourns
Features: Special Alloy Resistor
Height: 0.7 mm
Length: 6.4 mm
Mounting Style: PCB Mount
Product: Current Sense Resistors
Product Type: Current Sense Resistors
factory pack quantiy: 4000
Subcategory: Resistors
Type: High Power Current Sense Chip Resistor
Width: 3.2 mm
Unit Weight: 0.002046 oz

---
