| US$16,200.00-18,000.00 | 1 Piece (MOQ) |
| MODEL | UNIT | M7150A | M7150A | M7150A | M7163 | M7163 | M7163 | |||||
| Worktable size(WxL) | Mm | 500x1000 | 500x1600 | 500x2200 | 630x1250 | 630x1600 | 630x2200 | |||||
| Max matching dimension(W x L) | Mm | 500x1000 | 500x1600 | 500x2200 | 630x1250 | 630x1600 | 630x2200 | |||||
| Max distance between spindle center line and worktable surface | Mm | 700 | ||||||||||
| Longitudinal moving speed of worktable | m/min | 3-27 | ||||||||||
| T-slot number x W | Mm | 3x22 | ||||||||||
| Wheel head | Continuous feed speed | m/min | 0.5-4.5 | |||||||||
| Cross moving | Intermittent feed speed | Mm/t | 3-30 | |||||||||
| Hand wheel feed | Mm/gra | 0.01 | ||||||||||
| Vertical Moving | Rapid speed | Mm/min | 400 | |||||||||
| of wheel head | Hand wheel feed | Mm/.gra | 0.005 | |||||||||
| Wheel Head | Power | Kw | 7.5 | |||||||||
| motor | Rotation speed | Rpm | 1440 | |||||||||
| Total power | Kw | 12.25 | 13.75 | 15.75 | 13.75 | 15.75 | ||||||
| Max loading capacity of worktable (with chuck) | Kg | 700 | 1240 | 1410 | 1010 | 1290 | 1780 | |||||
| Chuck size(WxL) | Mm | 500x1000 x1 | 500x800 x2 | 500x1000 x2 | 630x1250 x1 | 630x800 x2 | 630x1000 x2 | |||||
| Wheel size (ODxWxID) | Mm | 400x40x203 | ||||||||||
| Machine dimension(LxWxH) | Cm | 311x190 x242 | 514x190 x242 | 674x190 x242 | 399x220 x242 | 514x220 x242 | 674x220 x242 | |||||
| Machine Weight | t | 5.78 | 7.32 | 8.78 | 6.86 | 7.85 | 9.65 | |||||
