C6256X2000 Precision Gear Head Lathe Bench Lathe Turning Center From China

US$3,000.00-18,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
C6256x2000
Processing Accessory
Metal
Guide Rail
Horizontal Guide Rail
Tool Holder
4 Tool Post
Power Source
Electric
Controlling Mode
Artificial
Automatic Grade
Manual
Setting Mode
Floor-type
Precision
High Precision
Certification
CE, ISO 9001
Condition
New
Transport Package
Standard Export Packing
Specification
2500/3000/3500/4500× 1100× 1650mm
Trademark
Alpha industries
Origin
China
Production Capacity
100 Sets/Year

Product Description

Product Description
The surface of the bedways is supersonic frequency hardened
The spindle bore size is 105mm.the spindle system is high rigid and accuracy
There is no need for change gears,the machine can turn about 89 kinds of metric,Inch,Module,and D.P.threads.
An automatic stopping device is used to realize automatic stop for the machining of a workpiece of certain length.
One-piece iron casting base allows heavier cuts.
Machine comes with rapid travel on apron
Product Parameters
Basic Info.
Model NO C6256x2000 Guide Rai HorizontalGuide Rail
Tool Holder 4Tool Post Power Source Electric
Controlling Mode Artificial Automatic Grade Manual
Setting Mode Floor-type Precision High Precision
Certification CE,ISO 9001 Condition New
Specification 3500×1100×1650 Trademark Alpha industries
Origin China ProductionCapacity 100 Sets/Year

Technical Parameters

Model No. Unit C6256x2000
distance between centers mm 1000/1500/2000/3000 (39.37"/59.06"/78.74"118.11")
swing over bed mm 560(22")
swing over carriage mm 420(16.54")
swing over gap mm 870(34.25")
spindle bore mm Ø105(4.13")
taper of spindle bore mm Ø113(4.45") 1:20
spindle nose D1-8
step of spindle speeds steps 12
range of spindle speeds rpm 36-1600
range of cross feeds mm/r 0.027-1.07
range of longitudinal feeds mm/r 0.063-2.52
range of inch threads/No. 28-2T.P.I/26
range of metric threads/No. mm 1-14mm/22
range of D.P. threads/No. 4-56D.P./24
range of mould threads/No. 0.5-7mm/18
rapid feed of cross traverse m/min 1.9
rapid feed of longitudinal traverse m/min 4.5
top slide travel mm 145(5.71")
cross slide travel mm 360(14.17")
max. size of tool(W×H) mm 25×25(0.98"×0.98")
tailstock quill travel mm 150(5.91")
tailstock quill diameter mm 75(2.95")
taper of tailstock quill MT5
motor kW 7.5Kw/11Kw available
packing size mm 2500/3000/3500/4500×1100×1650
N.W. kg 3200/3500/4000/4500

Standard Accessories

3 jaw chuck and adapter 4 jaw chuck and adapter face plate steady rest
follow rest oil gun thread chasing dial operation manual
one set of wrenches 2 dead centers sleeve foot brake
coolant pump halogen lamp splash guard micro carriage stop

Optional Accessories

quick change tool post driving plate taper turning attachment digital readout1.5/2/3)
Nr 12 standard for Brazil one piece iron casting stand

Company Profile
Certifications
Exhibition
Packaging & Shipping
FAQ
FAQs
Q1: How is the warranty?
A1: Warranty time is 15 months after BL date.
Q2: Can we visit your factory before order?
A2: Sure. All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3: Do you have a stock?
A3: We have stock for popular models, we produce according to order.
Q4: What's the MOQ?
A4: One set only.
Q5: How about your quality?
A5: We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 40 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6: Do you have professional engineers?
A6: Yes, we have professional engineers and designers. We can provide OEM services under Alpha brand.
Q7: Can you provide customized machines?
A7: Yes, we can design and manufacture according to your specific requirements.
