| US$2,000.00-20,000.00 | 1 Piece (MOQ) |
| Item | Z3063×20A | Z3080×25 | Z3080x20 | |
| Max.drilling dia. | mm | 63 | 80 | 80 |
| Distance between spindle and column | mm | 430-1930 | 500-2500 | 500-2070 |
| Distance between Spindle and base | mm | 290-1540 | 550-2000 | 350-1585 |
| Spindle taper(MORSE) | NO.5 | NO.6 | NO.6 | |
| Spindle travel | mm | 420 | 400 | 400 |
| Spindle speeds number | Steps | 16 | 16 | 16 |
| Spindle speeds range | r.p.m | 16-1250 | 16-1250 | 16-1250 |
| Number of spindle feeds | Steps | 16 | 16 | 16 |
| Range of spindle feeds | mm/r | 0.04-3.20 | 0.04-3.20 | 0.04-3.20 |
| Table size | mm | 630×800 | 800×1000 | 800X1000 |
| Lift motor | Kw | 1.5 | ||
| Main motor power | kW | 5.5 | 7.5 | 7.5 |
| Net/Gross weight | kg | 6500 | 9500 | 7000 |
