Direct Drive Motor AMKSDM-135-94

Product Details

Product Description

Product Description
DD motor benefits：
1.maintenance-free cross roller bearing
2.high efficiency and energy saving to improve productivity
3.can withstand load fluctuation
4.linear drive station plate to ensure high precision
5.high torque ,high precision
vide more convenient large center hole design
Motor type：AMKSDM-135-94
Maximum driving moment：7.32
Continuous driving moment：3.8
Maximum velocity：2940
Maximum driving current：5.3
Motor repetition accuracy：±1.3
Absolute accuracy of motor：±15
Outside diameter of motor：135
Motor internal aperture：90
Motor internal aperture：20
Motor height：94
Moment of inertia of the motor rotor（kg.m²）：1.50E-04
Motor torque constant：0.72
Back electromotive force constant of motor：44
Motor phase resistance：2.50
Motor phase inductance ：5.25
Motor pole number：20.0
Maximum power（W）：277.3
Motor constant：0.069
Maximum axial load：12000
Maximum load torque：300
No load axial runout（μ m)：A：10，B：20
No-load radial runout(μ m)：A：10，B：20
Motor weihgt（kg)：4.60

---
