HD3105-43 Durable CNC Milling Machine, Lathe, Machining Center for Industrial Applications

US$38,100.00-44,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
HD3105-43
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools, Metal-Forming CNC Machine Tools
Movement Method
Linear Control
Control Method
Closed-Loop Control
Numerical Control
CNC/MNC
Performance Classification
High-End CNC Machine Tools
Certification
CE, ISO 9001
Condition
New
Maximum Swing Diameter
740mm
Maximum Swivelling Diameter of The Bed S
656mm
Maximum Cutting Diameter
500mm
Maximum Cutting Length
708mm
Spindle Motor Power (Continuous/30 Min)
15/18.5kw
Maximum Spindle Speed
2800rpm
Spindle Nose
A2-8
Spindle Through-Hole Diameter
φ91
Bar Capacity
φ74
Collet Size
12"
Maximum Stroke X/Z
265/730mm
X/Z Axis Motor Power
Syntec:3.9 Fanuc:3
Fast Shift Speed X/Z
24/30m/Min
X/Z Slide Type
Box
Turret Capacity
12
Transport Package
Wooden Case/ Iron Box
Specification
3284x1817x1755mm
Trademark
wugan
Origin
China
HS Code
8458110090
Production Capacity
200pieces/Year

Product Description


Product Description
·One-bed,30° inclined bed, which significantly enhances its machining stability, ensuring precise and reliable performance.
·Equipped with hard rails on all axes, guaranteeing the production of high-quality products with superior vibration absorption.
· Achieves powerful rapid traverse speeds up to (X/Z): 265/730 m/min, boosting productivity.
·Features an optimal lineup of structures, including extended beds, turret punch presses, and servo axes to meet diverse customer needs.
·Compact design with an integrated motor, minimizing machine length in the standard bed style for space efficiency.
·Ergonomically designed for effortless operation and maintenance, ensuring user comfort and efficiency.
Product Parameters
basic specification Unit HD3105
Maximum Swing Diameter mm φ740
Maximum swivelling diameter of the bed saddle mm φ656
Maximum cutting diameter mm φ500
Maximum cutting length mm 708
spindle
Spindle motor power (continuous/30 min) kw 15/18.5
Maximum spindle speed rpm 2800
Spindle nose A2-8
Spindle through-hole diameter mm φ91
Bar capacity mm φ74
Collet size inch 12"
feed axis
Maximum stroke X/Z mm 265/730
X/Z axis motor power kw syntec:3.9 fanuc:3
Fast shift speed X/Z m/min 24/30
X/Z slide type Box
C-axis (optional )
Minimum spindle positioning accuracy
Dynamic accuracy
turret
Turret Capacity 12
Quadratic cutter mm 25
Round cutter mm φ50
Power Turret Motor Power kw
Power Turret Tool Specifications
Power tool speed rpm
tailstock
Mandrel Diameter mm φ100
Mandrel Stroke mm 120
Tailstock body stroke mm 730
Taper hole taper MT#5
Programmable Control Mandrel/Tailstock Body yes/no
Tailstock body movement method saddle-driven [Programmed
Mechanical specifications
Positioning accuracy (X/Z) mm ±0.007
Repeat Positioning Accuracy(X/Z) mm ±0.003
CNC system syntec or fanuc
chip conveyor sidebar
Exterior(L×W×H) mm 3284x1817x1755
Machine weight kg 5800

Detailed Photos
One-piece bed
Optimized structural analysis
Through sophisticated structural analysis, the main unit structure is optimized to reduce machine height and maintain the bed's dynamic rigidity during heavy machining, even in demanding conditions. The HD-3105's 30° inclined bed further enhances machining stability.
Integrated Cutting Fluid Tank
The cutting fluid tank is strategically mounted at the front of the bed for increased ease of use, while the machine's right side is designed to facilitate the cleaning of ferrous chips.
Hard Rail
The hard rails on all axes absorb vibrations excellently, even during heavy cutting, ensuring the production of high-quality products. The Z-axis, with its long shaft design, delivers exceptional performance, especially in machining long shaft products.
Sealed GIB Construction
The X-axis guideway mounting surface features a sealed GIB structure, which minimizes damage from cutting, thereby preserving the integrity of the X-axis guideway and enhancing durability.
6-sided constrained design improves mobility
Travel X/Y: 265/730 mm ·Spindle Box
The symmetrical design of the box body and the heat dissipation plate structure minimize thermal deformation. The shaft utilizes a combination of tapered roller bearings and angular contact ball bearings, providing robust cutting ability. The 3V belt, being the shortest, reduces vibration and extends lifespan.
Spindle specifications: A2-8 (chuck 12")
Spindle speed: 2,800 rpm
Motor power: 18.5/15KW
Suzhou Wugan Intelligent Equipment Co., Ltd. specializes in the production of high-performance CNC lathes and CNC turning centers, designed with the latest international lathe technology. Combining high rigidity, precision, productivity, and an exquisite appearance, we deliver efficient and reliable cutting performance. To meet the higher demands of our customers, we also offer a high-performance mill-turn combined model capable of turning, milling, drilling, and other combined processing functions. This multifunctional capability not only increases product output but also ensures that our lathes can easily meet the diverse processing needs of different customers.
