Feilong 68 Model High Speed Rapier Loom Weaving Loom Weaving Machine Textile Machinery Suitable for Denim, Industrial Fabric, Glass Fiber Staubli Dobby Jacuqard

Negotiable 1 Set (MOQ)

Basic Info.

Model NO.
Feilong 68
Computerized
Computerized
Precision
High Precision
Certification
ISO9001: 2000
Warranty
1 Year
Customized
Customized
Condition
New
After-sales Service
1 Year Guarantee Period
Transport Package
Standard Exporting Packing
Specification
190~600cm
Trademark
Zhongbo
Origin
Jiangxi
HS Code
6446302000
Production Capacity
1000 Sets/Year

Product Description

Product Description
Feilong 68 model high speed rapier loom adopts mature rapier weaving technology and absorbs the most advantageous international intermediate beating-up mechanism of loom and unique sword belt driving technology for perfect combination, improving weaving output of the latest loom. Its extremely solid fuselage structure ensures high stability and low solid fuselage construction which enables it to easily weave various heavy or other kinds of necessary fabrics.
Performance
· High speed
· Excellent fabric quality
· High efficiency
Investment & Use cost
· Low investment
· Fast return
· Long service life
· Low energy consumption
· Less maintenance
· Low consumption of spare parts
Simplicity
· Easy operation
· Quick replacement variety
· Wide variety adaptability

Product Parameters
Reed Width
190, 210, 220, 230, 260cm (narrow-weaving machine) 280, 340, 360 cm (wide-weaving machine),380cm,410cm, 520cm, 580cm, 600cm
Weaving shrinkage
70cm (narrow-weaving machine), 90cm (wide-weaving machine)
Loom drive
Directly driven by switched reluctance main motor
Speed
Designed maximum speed of 750 rpm, Economical speed of 550-600 rpm
Filling insertion rate
Up to 1425 m / min
Weft color selection
Programming of 1-8 color or different specifications.
Weft insertion
Unique weft insertion mechanism with the space connecting bar (patent).
16mm narrow sword belt, single guide flight system.
27mm wide sword belt, unguided flight system (optional).
Let-off
Servo motor control 850Kg weighing tension sensor.
Warp beam removing device
Double back rest system
Shedding
STAUBLI 2658B electronic rotating dobby Up to 20 head frame tappet motions (optional), jacquard head (optional).

There are nearly 20,000 units Feilong 68 model high speed rapier looms in operation on the market, mainly used in clothing fabrics, industrial fabrics and other fields, and are the main models for export.
Main techanic Datas:
1. The high-force torque motor is used as the main drive and powerful clutch to realize starting and braking, which maximizes the quality of the cloth surface;
2. Electronic dobby opening: up to 20 heald frames;
3. Space four-link mechanism weft insertion: separate reed seat, weft insertion on both sides, middle handover; There are two ways of guide hook weft insertion and free flight weft insertion;
4. Electronic let-off and electronic take-up realize constant tension weaving and variable weft dense weaving. Packaging & Shipping
The packaging details:
Company Profile
About us:
Jiangxi Zhongbo Intelligent Equipment Manufacturing Co., Ltd. is a high-tech enterprise dedicated to the integrated activities of research and development, production, and sales of high-end intelligent equipment. Situated in Fuzhou City, the cradle of Jiangxi's talents, Fuzhou is renowned as a city that is business-friendly, liveable, and inviting for travel.
Zhongbo Intelligent has introduced a range of intelligent, high-speed, information-based, and integrated high-end weaving equipment. The "ZBMax88" high-speed rapier loom, in particular, has attained the international advanced level and garnered the approval of users. Simultaneously, the company has unveiled intelligent equipment products such as intelligent high-speed rapier industrial cloth looms and high-speed rapier jacquard looms.
The core team members of the company are the cream of the textile machinery industry, a conglomeration of talents from fields including mechanical design, electrical design, software development, big data, and cloud computing. With characteristics like high speed, high efficiency, intelligence, wide adaptability, and user-friendly operation, they are designed to meet market demands. As a result, the company has developed a series of high-speed looms that stand as representatives of the world's most advanced and intelligent equipment.
Our company adheres firmly to the enterprise spirit of "dedication, integrity, efficiency, and innovation." We are committed to promoting the upgrading of the textile industry and wholeheartedly invite friends from all walks of life to join us in weaving a prosperous tomorrow.
Our Factory:
Our Team:
Our Advantages
WHY US?

01 Industry experience
With rich experience in the industry, Wetex gives professional guidance and advice according to the needs of customers.
02 Customer Oriented
Wetex always puts customer's satisfaction as the first place, from professional sale suggestion, order tracking, to after sale one-site service, offering customer a life-cycle support.
03 Long-term cooperation
Wetex offer long warranty period, flexible payment methods, online and offline exclusive services, etc. are all to ensure long-term and stable cooperation
04 Own factory endorsement
FAQ
1.Q:What are your payment terms?
A:L/C,D/A,D/P,T/T,Western Union,MoneyGram
2.Q:What is your logistics method?
A:Express,sea,lan,air
3.Q:How long is your lead time?
A:30-90 Days
4.Q:How about your after-sales service?
A:We offer engineers available to service overseas under merchandiser's supervision and translation
5.Q:Can i go to the factory for a field trip?
A:Welcome to our old and new friends to visit our factory very much,In addition,if you wish we will send you our instructions and relevant information to facilitate a face-to-face meeting
