Basler ace alA640-300gm

Product Details

Product Description

Product Description
The Basler acA640-750um USB 3.0 camera with the ON Semiconductor PYTHON 300 CMOS sensor delivers 751 frames per second at VGA resolution.
General Information
Order NumberProduct FamilyProduct LineCamera Category

106748

ace U

ace U

Area Scan Camera

Sensor
Sensor VendorSensorShutterSensor FormatSensor DiagonalSensor TypeSensor SizeResolution (H x V)ResolutionPixel Size (H x V)Frame rateMono/ColorSpectrum

onsemi

PYTHON 300

Global Shutter

1/4"

3.84 mm

CMOS

3.07 mm × 2.3 mm

640 px x 480 px

VGA

4.8 μm x 4.8 μm

751 fps

Mono

Visible

EMVA Data
Quantum Efficiency (typical/minimal)Dark Noise (typical/maximal)Saturation Capacity (typical/minimal)Dynamic Range (typical/minimal)Signal-to-Noise Ratio (typical/minimal)

52 % (typical)

10.5 e¯ (typical)

7.1 ke¯ (typical)

56.6 dB (typical)

38.5 dB (typical)

Camera Data
InterfaceImage Data InterfacePixel Bit DepthExposure ControlDigital InputPower SupplyPower Requirements (typical)

USB 3.0

USB 3.0, nominal max. 5 Gbit/s (SuperSpeed)

10 bits

hardware trigger programmable via the camera API

1

Via USB 3.0 interface

3 W

Housing
Housing TypeHousing Size (L x W x H)WeightLens MountOperating Temperature

Box

29.3 mm x 29 mm x 29 mm

80 g

C-mount

0 °C - 50 °C

Manufacturer
Basler

---
