Cheap and Economical New Energy Vehicle Electric Vehicle EV E-Bus Electric Car 4 Wheeler Equipped with Lithium Battery

Product Details

Product Details

Product Description

Product Description
Product Parameters
No.ItemVehicle modelA02A13
-RHD
1Basic parameters and structureOverall dimensions (L*W*H) (mm)3500×1500×15403500×1500×1540
2Wheel base (mm)23452345
3Wheel track (front/rear) (mm)1310/13001310/1300
4Min. groud clearance (Full load) (mm)≥130≥130
5Min. turning radius (m)≤4.7≤4.7
6Weight of No battery (kg)690690
7Curb weight (kg)830895
8Gross vehicle weight (kg)11301195
9Max. speed (km/h)YES100YES100
10Max. speed (km/h)
(if adopts rear axle10:1 speed ratio)
○85○85
11Max. slope of climb (%)YES≥20YES≥20
12Max. slope of climb (%)
(if adopts rear axle10:1 speed ratio)
○≥30○≥30
130~50km/h acceleration time (S) (s)≤6≤6
140~50km/h acceleration time (D) (s)≤10≤10
15Power Battery TypeLithium Iron PhosphateLithium Iron Phosphate
16Battery capacity (kwh)15.2123.96
17Rated/Peak motor power (kW)13/2513/25
18Max. torque (N·m) 100100
19Motor typePermanent Magnet SynchronizationPermanent Magnet Synchronization
20Driving range (CLTC,KM)≥170≥260
21Driving typedirect drive of Rear axle direct drive of Rear axle
22Cooling mode of Dynamic systemNatural coolingNatural cooling
23Charging time (h)5-68-10
24External discharge function××
253.3kw motor (3.3 kw charger)YESYES
262kw motor(2kw charger)××
27220V chargerYESYES
28Auxiliary battery(AH)3232
29Body structureBody typeLoad-bearing bodyLoad-bearing body
30Body structureFive doors and four seatsFive doors and four seats
31Number of doors55
32Double sealing strip for doorYESYES
33Suspension structureFront SuspensionMcpherson independent suspensionMcpherson independent suspension
34Rear SuspensionTowed arm non-independent suspension(Straight arm)Towed arm non-independent suspension(Straight arm)
35Rear axle (Speed ratio)YES8.147YES8.147
36Rear axle (Speed ratio)○10○10
37TyreTire Size155/65 R14 155/65 R14
38Steel Wheel YESYES
39Aluminium Wheel
40HubcapYESYES
41TurnSteering WheelInjection molding + foamingInjection molding + foaming
42Steering gear typeRack and pinion typeRack and pinion type
43Mechanical steering assist××
44Electronic steering assistYESYES
45BrakeFront/rear brakeDisc Brake/Drum BrakeDisc Brake/Drum Brake
46Parking brakeMechanical handbrake, acting on the rear wheel Mechanical handbrake, acting on the rear wheel
47Electric vacuum boosterYESYES
48Humanized designDriver Seatbelt warning YES/×YES/YES
49Parking WarningYESYES
50Open Door Danger Warning YESYES
51Remote Control Key YESYES
52Glass lifting Four-door electricFour-door electric
53Glass - key liftingone-button drop window of driverone-button drop window of driver
54Automatic window lifting at locking car××
55Shift Mode of Knob TypeYESYES
56Wiperboneless wiper boneless wiper
57Back door opening wayElectronic switchElectronic switch
58Children lockYESYES
59Same color door handleYESYES
60Interior and exterior decorationMain driver seat adjustmentManual four directionsManual four directions
61The passenger seat AdjustmentMANUAL four directionsMANUAL four directions
62Recline the Rear SeatYESYES
63Seat fabric ClothYESYES
64Seat fabric with PU
65Main Driver/Passenger 3-point seatbeltYESYES
66The Rear SeatbeltYESYES
67The main drive visorYESYES
68Passenger visor YESYES
69The main drive visor with makeup mirror××
70Passenger visor with makeup mirror××
71Centrol BoxYES×
72Front Reading LightYESYES
73Manual Rearview Mirror××
74Electric Rearview MirrorYESYES
75Anti-dazzle inner rearview mirrorYESYES
76Inside rearview mirror with Traffic recorder××
77Tail wingYESYES
78Front protecting beamYESYES
79Two-color body
80Black film for window frameYESYES
81Luggage rack××
82Function and configurationHeadlampHeadlamp of Lens halogenHeadlamp of Lens halogen
83Adjustable Headlamp Height YESYES
84Follow Me Home Lamp YESYES
85Driving Automatic Lockout SystemYESYES
86Air ConditionerManual operationManual operation
87PM2.5 Air conditioning filter element××
88Air conditioning auto-cleaning/auto-ventilation function××
89Daily Running LightYESYES
90Flowing turn lightYESYES
91LED decorative lamp××
92Rear fog lampYESYES
93Halogen back lightYESYES
94LED back light××
95High brake lightYESYES
96Through type tail lights×YES
9712V Power PortYESYES
98LCD Meters Monochrome liquid crystal +LEDMonochrome liquid crystal +LED
99Vehicle Central Locking ControlYESYES
100Hidden mechanical door handle××
101Whip antennaYES×
102Shark fin antenna×YES
103Rearview mirror with LED turn lightYESYES
104Intelligent safety systemDriver/front Passenger AirbagYES/×YES/YES
105EDR digital data recording systemYESYES
106ABS/EBDYESYES
107Tire Pressure WarningYESYES
108Brake Energy Recovery SystemYESYES
109Pre-heating of BatteryYESYES
110Battery with heatingYESYES
111Rear ISO-FIX child seat portYESYES
112HAC Ramp assist systemYESYES
113Driving modeE/S/D driving modeE/S/D driving mode
114Flameout-unlockYESYES
115Intelligent recharge of accumulator××
116Power battery protection system××
117Automatically power off at high voltage failure YESYES
118Automatic blackout at crushingYESYES
119Intelligent voice prompt××
120Millimeter-wave RadaYESYES
121One-button start××
122Low Speed Pedestrian Alert System YESYES
123Entertainment systemSpeakers Number22
124Radio××
125BluetoothYESYES
1269 inch MP5 control Screen (with radio)YES×
12710.25 inch LCD Screen ×YES
1284G Car Terminal(T-BOX)××
129Vehicle Backup Camera YESYES
130USB(with power port)1 PC1 PC
131Vehicle toolReflective vestYESYES
132Triangle warningYESYES
133Front towYESYES
Remark:
"YES" means with this configuration, "×" means without this configuration, and "○" means optional.

FAQ
Q1: Can I have samples before mass production?
A:Yes,we have sample stock in Munster, German, you can order sample first. Please notice that our sample price is different from mass production prices
Q2: Do you have overseas service center?
A: Yes, we have service centers in Europe and we provide call center, maintenance, spare parts, logistics and warehousing services covering the whole of Europe, support door to door transport, returning process etc.
Q3:Do you accept OEM or ODM?
A:Yes we would accept OEM in certain year purchase quantity. Right now the minimum order quantity is 10,000 per year.
Q4:Can I add my own logo or choose my own colors?
A:Yes you can. But for change logo and colors, the MOQ is 1000 pieces per order or for specific discussion.
Q5: Do you have e-bike, e motorcycle?
A: Yes we have e-bike and e motorcycle, but currently we cannot do dropshipping support.
Q6:What is the payment term?
A:For sample order,it's 100% TT advance.
For mass production order,we accept payments TT, L/C,DD,DP, Trade Assurance.
Q7:What is your delivery time?
A: For sample order,it should take 2 week to prepare and shipping time depends on distance from our warehouse in Europe or US to your office location
For mass production order,it will take 45-60 days of production and shipping time depends on sea freight
Q8: What certificate do you have?
A: We have CE,TUV, KBA, FCC,MD, LDV, RoHS, WEEE etc. Also we can provide any certificate relates to products.
Q9: How does your factory perform quality control?
A: We would start quality control process since the beginning of production. During the whole process we would proceed IQC,OQC,FQC, QC, PQC and etc.
Q10:.What's your after-sales service like?
A:The whole product warranty of our product is 1 year, and for agents, we will send some spare parts and provide maintenance video to help them repair together. If it is the cause of the battery or the damage is serious,we can accept the refurbishment of the factory.
Q11: Where is your factory located? How can i visit your factory?
A: We are a group company, different product produced in different city due to we are making full use of industrial resources and supplying chain, now we have more than 6 production bases of electric scooters in Zhejiang, Guangdong ,Jiangsu, Tianjin etc. Please contact us for arrange visits.
