US$66.00
|
200 Pieces
(MOQ)
|
Basic Info.
Function
Storage Pressure Vessel
Pressure
10.0MPa≤p<100.0MPa
Storage Medium
Flammable/Toxic
Pressure Level
High Pressure (10.0MPa≤p<100.0MPa)
Working Pressure
150bar, 200bar
Transport Package
Carton/Wooden Case/Pallet
Specification
GB, EN, DOT, ISO
Production Capacity
200, 000 Pieces/Year
Product Description
Alsafe Company devoted in the field of Aluminum gas tank for a decade.
Products are well received at the global market all the time.
Products are applied extensively in fields of beverage processing.
CE/TPED approved.
| Items | Overview |
| Materials | High strength Aluminum alloy 6061 |
| High standard of safety | Hydro-test before delivery |
| Lightweight | 40% Weight-saving compared with steel cylinder |
| Strong and thick wall | Design to ensure anti-pressure strength |
| Smart appearance | Brushed Aluminum body and need low maintenance |
| Service pressure | 150bar |
| Technical standard | EN, DOT,ISO upon customers' demand |
| Fitted valve | CGA320 or upon customers' demand. |
| Life-span of product | 15 years |
| Recertification period | 5 years |
| Delivery time | 6 days to 30 days upon deposit. Shipping empty. |
. Highlight of Manufacturer provides150bar Aluminum CO2 Tank:
. Excellent performance under low temperature. Highly anti-corrosion.
. Light and strong handle fitted for upwards of 20L tank free of charge.
. Date of manufacturer within 30 days.
| Type | Outer Diameter | Water
Volume | Length of
cylinder | Weight of
cylinder | Filling CO2 |
| mm | Lr | mm | kg | kg | lb |
| LW-203-8.0-15-H | 203 | 12 | 435 | 9.9 | 4.8 | 10.6 |
| LW-203-10.0-15-H | 203 | 10 | 511 | 11.4 | 6 | 13.2 |
| LW-203-11.4-15-H | 203 | 11.4 | 570 | 12.4 | 6.8 | 15 |
| LW-203-12.0-15-H | 203 | 12 | 587 | 12.8 | 7.2 | 15.9 |
| LW-203-13.4-15-H | 203 | 13.4 | 640 | 13.8 | 8.04 | 17.7 |
| LW-203-15.0-15-H | 203 | 15 | 710 | 14.9 | 9 | 20 |
| LW-203-16.6-15-H | 203 | 16.6 | 763 | 15.6 | 10 | 22 |
| LW-203-20.0-15-H | 203 | 20 | 873 | 17 | 12 | 26.4 |
. Product details:
. Packing in cartons / pallets with cushion materials:
>>
