| Model No. | 2513T-1D | |
| Platform Dimension: | 2500*1300mm | |
| Working Size: | 2400*1250mm for 1 piece | |
| Machine Body: | Thickened Steel (10mm) | |
| Working Table: | Aluminum T-Slot Table with PVC Plate | |
| Linear Guide Rail: | Y Axis PMI-25 (Two Guide Rails); X Z Axis PMI-30 | |
| Transmission: | X Y Axis Helical Rack; Z Axis Ball Screw with A Brake | |
| Feed Height: | ≤400mm | |
| Air Speed: | 20m/min | |
| Processing Speed: | 20m/min | |
| Spindle Power: | 7.5kw Water Cooling Spindle (Frequency Conversion) | |
| Spindle Speed: | 6000-24000rmp/min | |
| Drive: | Full Servo Drive | |
| Motor: | Full Servo Motor | |
| Reducer: | JZ8098 | |
| Lubrication: | Automatic Lubrication | |
| Coolant System: | Industrial Coolant System | |
| Water Tank: | Stainless Steel | |
| Operating Voltage: | AC220V/50HZ or AC380V/50HZ | |
| Engraving Tool: | Φ6/8/10/12/14/16mm | |
| File Format: | G code/HPGL | |
| Positioning Accuracy: | ±0.02mm | |
| Repeatability: | ±0.01mm | |
| Control System: | NC Studio | |
| Machine Dimension: | 3800*2300*2300mm | |
| Weight: | 2200kg |
