Product Description
Product Description
Description• Sierra SL6087 is a 2G GSM/GPRS/EDGE Quad band programmable module. Supported frequency bands: 2G 850/900/1800/1900. Support for OpenAT embedded application framework and AirVantage management services is integrated. Form factor: 25x30 mm, SMD LGA package.• AirPrime® SL Series come in standard LGA packages for cost-effective, fully-automated high-volume production. Ensure easy upgrade paths to next-generation network technologies with a wide selection of air interfaces. Accelerate your M2M development and deployment with its application framework and cloud-based device management services.Sierra AirPrime SL6087 module Specifications:Features• Air interface: 2G GSM/GPRS/EDGE• 2G Bands: 850/900/1800/1900 MHz• Form factor: SMD LGA package, 25x30x2.65mm• Supply Voltage: 3,6V nominal• Operating Temperature: -40°C to +85°CControl, software and features• Control options: AT Commands, C/C++ through OpenAT• Internet services: TCP, UDP, FTP, HTTP, SMTP, POP3, SNMP, SSL• Drivers: Android, Windows, Linux• Cloud service: AirVantage Management Services ready• OpenAT embedded application frameworkEmbedded application performance• CPU: ARM946/DSP• Core frequency: 26-104 MHz• User MIPS available: 70 MIPS• Memory: Embedded Flash and RAMInterfaces• UART: 1x 4 wire and 1x 8 wire• USB: 1x 2.0 Full Speed• SPI: 1x 4 wire• I2C• ADC: 2x• GPIO: up to 26• li>RTC• Timers (HW, SW, Capture)• Interrupt: 2x• Flash LED output• PWM (Buzzer)• Tx Burst indicator• SIM interface: 1.8/3VAudio• Analog audio: 1x microphone, 1x speaker• Digital audio: PCM• Codec: FR, EFR, HR, AMR• Quality: VDA2A• Echo cancellation• Noise reduction• DTMF (Encode and Decode)Benefits• Easy upgrade path to new network technologies• Investment protection with remote monitoring and upgrade• Supports efficient and reliable high volume production requirements• Manufacturing technology excellence• Supports industrial requirements with extended temperature and embedded SIM• Compatible with standard 25x30mm LGA form factorWhy Choose UsFAQQ1. What is the minimum order quantity for your products?A1. Minimum order quantity starts from ONE piece.Q2. What's the quality of your products?A2. We have professional QA/QC team to ensure the quality before shipment. We provide 1 year warranty for all the new and original products.Q3. Is this product free of shipping or free samples?A3. Regularly the sample and shipping cost will be at the buyer's account. But in specific case, we may take these costs. Please kindly check with us the details by email. Thank you.All Categories4G 5G ModuleGPS ReceiverGPS AntennaGSM/LTE/WiFi AntennaGSM/LTE+GPS AntennaGNSS/GPS Module2G/3G/4G ModemGPS TrackerRF Coaxial / ConnectorSIMCard HolderSensorIC
>>
