Popular Xz680 Horizontal Directional Drilling Machine Price

Product Description

Popular XZ680 Horizontal Directional Drilling machine Price
Specifications
XZ680 Horizontal Drictional Drill
Dongfeng Cummins (250KW) engine
Backreaming diameter: 1000 mm
Cummins (250kW) turbocharger water cooling engine, self-propelled steel tracks chassis, high strength box-type slideable drilling frame, closed circuit and load sensing control hydraulic system, rack and pinion push-pull, two shift gears speed transfer, air conditioning cab, wire controlling walk, floating spindle, onboard high-capacity mud pump (600L/min) and equipped with truck mounted crane.
Technical Features of XZ680:
Hydraulic system: It adopts advanced control technologies such as closed energy-saving circuit and electro-hydraulic proportional control. It adopts imported elements which features reliable quality.
Slewing: Driven by low speed and big torque motor, with two speed gears, and automatic high pressure protection.
Push/pull: Gear rack type, two speed gear stepless speed regulation, high work efficiency.
Cab: Mounted with air conditioning system, the cab is very comfortable.
Engine: The large power reserve engine meets the requirements for operating power and emergency control.
Drill mounting: The assembled high strength drill mounting can slide and the angle adjustment is convenient.
Drill stem holder: The suspended holder and truck-mounted crane make the assembly/disassembly of drill stem more easy and efficient.
Track: The self-propelled steel track is more efficient for site transfer.
Wire controlled travel: Wire controlled travel make the site transfer more quick and convenient.
Monitoring: The monitoring and alarm on multiple parameters of engine, hydraulic system, and filtration effectively ensures machine safety.
Emergency operation: The manual operation system can cope with special situations and protect the operating safety.
Model

XZ680

Engine		SUMMINS
Rated power	kW	250
Max.pullback/thrusting	kN	680/680
Spindle torque(max)	N.m	27000
Spindle speed	r/min	0-100
Backreaming diameter	mm	Ø1000
Tubing length(single)	m	6
Tubing diameter	mm	Ø102
Entry angle	°	10-18
Mud flow rate(max)	L/min	600
Mud pressure (max)	bar	100
Overall weight	kg	25000

---
