All-in-One Pipe Cutting and Beveling Machine

US$20,000.00-100,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
AUTO MPFS
Suitable for Material
CS/Ss/as
After-Sales Service Provided
Engineers Available to Service Machinery Overseas
Applicable Industries
Oil&Gas, Refinery Facilities, Offshore&Shipbuildin
Control Mode
PLC
Cutting Accuracy
1mm
Transport Package
Packed in Container
Specification
ISO9001: 2008
Trademark
NAEC
Origin
China
HS Code
85153190
Production Capacity
200 Sets/Year

Product Description

NAEC---- Lean Fabrication Service Operator for Energy Engineering Industry!
Suitable for industries of: OIL AND GAS, REFINERY FACILITIES, OFFSHORE &SHIPBUILDING, POWER PLANT, ETC.
Reference: CCC, Larsen & Toubro, PEC, Rotary Engineering, Petrol Steel, JSL, Tamimi, AIM, CNPC, SINOPEC, CNOOC, CNCEC, etc.
3D Video of All-in-one Pipe Cutting and Beveling Machine
Features:
1 One cut-off with two pipe end beveling
2 High speed pipe cutting & beveling
3 Suitable for small pipes
4 Max. Thickness: 20mm
5 Cutting efficiency: 100 times/8hrs
6 PLC control with automatic measuring function
7 Widely used for small bore C. S/S. S pipe spooling fabrication production lines.
Pipe Spool Fabrication Machines
1 Pipe Cutting& Beveling All-in-one Machine
>Suitable for pipes not larger than 8",max.thickness:20mm
>Cutting efficiency:100times/8hrs
>PLC control with automatic measuring to guarantee the same processing cycle
>Widely used for small bore C.S/S.S production lines
2 High Speed Band-saw Cutting Machine
>Three models available(16"type,24"type",48"type)
>PLC system control;self-measuring function with precision:±0.5mm
>Using hydraulic self-centering chuck
>It only takes 6 minutes to cut a 24" pipe of 25mm thickness
>Widely used for C.S/S.S production lines.
3 High Speed CNC Pipe End Beveling Machine
>Automatic self-centering chuck
>Single V,double V,U type bevel
>Can be matched with pipe end turning devic
>High speed beveling:for example,it only takes 2.5minutes to get a 37.5 degree bevel for a S.S pipe end(diameter :610mm,thickness:25mm)
>Several models available:16",24",32",48"
4 Two / Multi- Axis CNC Flame/Plasma Cutting Machine
>High efficient pipe cutting with automatic self-measuring function, pipe end beveling, intersection line profiling for both main and branch pipe.
>Five/multi-axis cutting machine can profile more complicated outlines with various bevel type
>Standard machine suitable for pipes nor larger than 24''
5 Multi-function Pipe Fitting-up Station
>Suitable for flange,elbow,tee,reducer to pipe and special T-joint fitting-up.
>Light-duty type(manual) and heavy-duty type(motorized) are available.
>Different types available, 8" type, 24" type, 32" type, 48" type, 60" type
6 Automatic Pipe Welding Station
>With two welding heads
>TIG/MIG/SAW are optional
>PLC system control & WPS programmed
>Max. efficiency fo reach welding head can be 400D.I/8hrs even use TIG/MIG technology.
>Different types available, 8" type, 24" type, 32" type, 48" type, 60" type
7 Conveyor Handling System
>used for pipe convenient transporation during in pipe spool fabrication.
>Its speed is adjustable between 2M to 20M/min.
For more information, please contact us, thank you!
For the 3D Video of All-in-one pipe cutting and beveling machine, you can also see it from below link: http://youtu.be/YS6vCgrV7Lo
