1000KGS 1500KGS Full electric roll lifter rell lifter roll stacker

US$2,000.00-2,500.00 2 Pieces (MOQ)

Basic Info.

Model NO.

CDD1000R, CDD1015R,CDD1500R, CDD1515R

capacity

1500kgs, 1000kgs

lifting height

865mm, 1500mm

motor

2.2kw

battery

24v/120ah

charger

24v/10a

Transport Package

1PCS/Pallet

Specification

CE

Trademark

NU-LIFT

Origin

Jiangsu, China (Mainland)

HS Code

8427900000

Production Capacity

1000 Pieces / Month

Packaging & Delivery

Package Size

180.00cm * 85.00cm * 21.00cm

Package Gross Weight

400.000kg

Product Description

•Capacity:1000Kg, 1500Kg.•Lifting Height:865mm, 1500mm.•This series lifters are fully automatic type ,which means electric lift and electric move .•This Roll Lifters are designed for handling Large and heavy material rolls .•Unique tray design with Electric Front Lip effectively protect rolls from rolling , especially on uneven ground , this device is essential for safety .•Structure made of high resistance steel rolled sections to ensure the highest degree of strength and durability.•Using this lifters, material damage is reduced or eliminated when moving rolls.•Customiztion for various of rolls' sizes and lifting height are acceptable.

Model		CDD1000R	CDD1015R	CDD1500R	CDD1515R
Type		Electric Lifting & Electric Moving
Capacity	(kg)	1000		1500
Lift Height	(mm)	865	1500	865	1500
Roll Tray Width	(mm)	800		1100
Max.Roll Width	(mm)	1550		1700
Max.Roll Diameter	(mm)	1000		1200
Lifting Motor	kw	2.2
Travelling Motor	kw	0.75
Travelling Speed	km/h	0~5
Battery	Ah/V	120/24
Charger	A/V	10/24
Front Roller	mm	78X70
Drive Wheel	mm	210X70
Net Weight	(kg)	393	415	453	475
