Customized Lateral Blade Compounder Industrial Cooper Powder Mixing Facility

Product Description

The Horizontal Ribbon Mixers are versatile and essential machines commonly utilized for the mixing, stirring, and blending of powders, granular materials, slurries, or viscous substances. Designed to accommodate a variety of processing needs, they can be outfitted with a liquid spraying system and customized to function under vacuum, pressurized, heated, or cooled conditions, depending on user requirements. This extraordinary versatility ensures that these mixers meet the demanding mixing and stirring needs of materials under diverse process conditions. Horizontal Ribbon Mixers are indispensable in the chemical, pharmaceutical, food, and building materials industries. They excel in mixing powder with powder, combining powder with a small amount of liquid, and integrating powder with granules.
The Horizontal Ribbon Mixer is composed primarily of a mixing chamber and a stirrer drive device. Within the U-shaped tubular chamber, a double-layered, counter-rotating ribbon spiral agitator shaft is installed. The outer spiral ribbon, driven by power, moves materials from both ends of the U-shaped chamber toward the center, while the inner spiral ribbon pushes materials from the center toward the ends, creating a dynamic and efficient convective mixing effect. creating a convective mixing effect . The discharge port is strategically located at the center of the chamber's bottom. The unique spiral design of the outer ribbon, combined with the rotation of the main shaft, directs the material inside the chamber toward the central discharge port, ensuring seamless discharge without dead corners .
Product Features
1. Cantilever Shaft Structure, with bearing ends that do not come into contact with the material, ensuring longevity and cleanliness.
2. The minimal gap between the agitator blades and the container wall effectively prevents material adhesion .
3.
A standardized agitator drive box ensures consistent equipment operation and significantly reduces maintenance costs.
4. Easy-Cleaning : Designed for rapid and thorough cleaning between batches;
5. Durable Construction : Engineered with robust materials to ensure long-term reliability;
6. Wide Application : Ideal for use across various industries including pharmaceuticals, food processing, chemicals, and cosmetics.
Technical Parameters

Product Model	RX-LDH-0.3	RX-LDH-0.5	RX-LDH-1	RX-LDH-2	RX-LDH-3	RX-LDH-4	RX-LDH-5	RX-LDH-6	RX-LDH-8	RX-LDH-10	RX-LDH-15	RX-LDH-20	RX-LDH-30
Effective Volume (m3)	0.18	0.3	0.6	1.2	1.8	2.4	3	3.6	4.8	6	9	12	18
Maximum Batch Output (kg)	200	300	600	1200	1800	2500	3000	3600	4800	6000	9000	12000	15000
Rotation Speed (r/min)	62	62	49	33	33	27	27	27	22	22	14	14	12
Drive Power (kW)	5.5	7.5	11	15	18.5	22	30	37	45	55	75	90	110
Equipment Weight (kg)	600	900	1200	2000	2500	3500	4000	4500	5000	6000	7500	10500	13000
Length	2280	2670	3140	3860	4460	4950	5280	5530	2100	5610	5820	6300	7000
Width	680	780	980	1200	1300	1400	1550	1560	1720	1750	2000	2350	2600
Height	880	1240	1400	1650	1700	2000	2100	2200	2500	2650	2900	3160	3350

Product Display
Product StructureApplication
The Double Cone Mixer is versatile and can be utilized in industries such aspowder metallurgy, electrical alloys, magnetic materials, battery powders, pearlescent pigments, chemical industry, medical, and food sectors
.About Our Company Shijiazhuang Rongxin Technology Co., Ltd.
was established in 2007, with its headquarters in Shijiazhuang, the capital of Hebei Province. Specializing inthe innovative design and provision of material handling automation systems, our company has earned a distinguished reputation as a leader in the industry. We have secured numerous patents and accolades, including recognition as a 'National High-Tech Enterprise' and an 'Innovative Enterprise.'
At Shijiazhuang Rongxin Science and Technology Co., Ltd, we pride ourselves on our diverse and innovative product lineup. Our cornerstone offerings include state-of-the-art dust-free enclosed feeding systems, advanced sealed conveying systems, robust pneumatic conveying systems, and cutting-edge tube chain conveying systems. These sophisticated solutions are meticulously designed for seamless integration across various sectors including the metal materials industry, food processing industry, chemical industry, pharmaceutical industry, and the burgeoning new energy industry.Moreover, we are empowered by our proprietary production facility, featuring well-established and mature manufacturing lines. This ensures that every piece of equipment we produce upholds the highest standards of quality and reliability. Company Certification
