| Classify | Items | Parameters | |
Chassis specs | Model of chassis | DFL1250A9 | |
| Manufacturer | DongFeng Motors Co.,Ltd. | ||
| Total curb weight kg | 16085 | ||
| Load capacity kg | 8685 | ||
| Max speed km/h | 85 | ||
| Overall dimension mm | 11960×2500×3790 | ||
| Carriage dimension mm | 8300×2294×550 | ||
| Passengers | 3 | ||
| Wheelbase mm | 5700+1300 | ||
| Distance of front and rear wheels mm | 1940/1860/1860 | ||
| Drive mode/Number of shafts | 6X4/3 | ||
| Approaching angle/Departure angle ° | 29/10 | ||
| Front suspension/Rear suspension mm | 1250/3500 | ||
Engine | Model of engine | C300-33 | |
| Power of engine Kw/Hp | 221/300 | ||
| Engine output volume ml | 8300 | ||
| Exhaust standard | EURO 3 | ||
| Motor manufacture | DongFeng Cummins Diesel Engine Co.,Ltd. | ||
| Specs of loading crane | ITEM | UNITS | Crane model |
| SQ12SK3Q | |||
| Max lifting capacity | KG | 12000 | |
| Max lifting capacity | T.M | 30 | |
| Recommend power | KW | 30 | |
| Max oil flow | L/MIN | 63 | |
| Max pressure | MPA | 26 | |
| Oil Tank Capacity | L | 160 | |
| Crane weight | KG | 4200 | |
| Installation space | MM | 1300 | |
| Rotation angle | DEGREE | 360 All Rotation | |
| Max extension length | MM | 12500 | |
| Max lifting height | MM | 13500 | |
| Max elevation | DEGREE | 75 | |
