Hygienic Sanitary Stainless Steel Pneumatic 3PCS Tank Bottom Ball Valve

Product Description

Wenzhou Santhai Valve Pipe Fittings Co., Ltd (Since 2006)
Product Description It Is Widely Used In Beverage, Brewing, Oil Refinery, Cosmetic, Chemical Industries.
˙ Free of maintenances
˙ Compact and portable
˙ Small operating torque
˙ Gasket complies with PTFE FDA 177.2600
˙ Hand lever can be installed on the side of the valve body, no matter of the flow direction.
˙ Connection ends: thread, clamp, weld,flange, DIN, SMS, RJT, FIL.
˙ It can match with pneumatic and electricactuators.
˙ Material for the part contacted with media is AISI 304/316L. Other part is AISI 304
˙ Type of valves: One way ball valve, three-piece ball valve. Three-way ball valve
˙ Type of cores: T type, L type, direct type.
˙ Material quality:AISI 304,316L

Product Parameters

Material	AISI304 AISI316L
Specification	DN25-100 & 1"-4"
Standard	ISO, DIN, 3A,SMS etc
Connection	Welded, Clamped, Threaded, Flanged
Working Principal	manual operation or driving device operation
Flow pattern	straight
Seat material	PTFE, PCTFE, PEEK or upon your request
Orifice size	2mm to 4.8mm
Body construction	3-piece precision cast body
Temperature	-20degree celsius~135degree celsius

Detailed Photos
High Quality DIN SMS Clamped Type Sanitary Ball Valve
Application:
Ball valve is well used in food, beverage, chemical and cosmetic industries to control medium flow. The full port design with zero restriction makes it an optimum choice for viscous and particulate liquids.

Working Principle:
Manual ball valve can be operated through actuator(90 degree rotary handle), actuator with the hand is to revolve the axial movement unto 90 degree, so the valve can open or close.
Pneumatic actuator is to covert the axial movement of piston to be 90 degree rotation of valve shaft, so that the valve can be open or close to achieve the requirement of control and open /close for the pipeline system.

Standard Design:
Various standards of ball valves can be provide can be provided to clients: DIN, 3A, SMS, ISO/IDF, BS/RJ, ASME/BPE etc.
Main Details:

Body Material	SS304/ SS316L
Seal Material	PTFE+EPDM(Double Layer)/EPDM/Silicon/FPM/FKM
Standard	DIN/SMS/IDF/3A/BPE/ ISO
Size	1/2" to 4" (DN15-DN100)
Working Pressure	1.6~6.4Mpa
Working Temperature	-10 to 121 degree C
Connection End	Threaded/Welded/Clamped End/Union
Available Structure	Straight way type/ Three ways type
Surface Polish	Internal(Ra<0.6um), External(Ra<1.6um)
OEM	Available
Shipment Way	By Sea (Ningbo/Shanghai Port), By Air, By Express
Term of Payment	100% T/T, 30% advance and balance 70% before delivery.
Packaging Details:	Bubble pack for each within carton box; Plywood case is also available for sea transportation.

Certifications
Packaging & Shipping
Company Profile

Sanitary Valves	Sanitary Butterfly Valves
	Sanitary Check Valves
	Sanitary Ball Valves
	Sanitary Divert Valves
	Sanitary Diaphragm Valves
	Sanitary Sample Valves
	Sanitary Mixproof Valves
Sanitary Pipe Fittings	Sanitary Elbow
	Sanitary Tee
	Sanitary Reducer
	Sanitary Cross
	Sanitary Triclamp Ferrule
	Sanitary Cap
	Sanitary Pipe Hanger
	Sanitary Tank Cleaning Ball
	Sanitary Hose Joint
	Sanitary Unions
	Sanitary Sight Glass
	Sanitary Strainer
Sanitary Manways	Sanitary Round Manway without Pressure
	Sanitary Round Manway with Pressure
	Sanitary Square Manway
	Sanitary Oval Manway
Sanitary Pumps	Sanitary Centrifugal Pump
	Sanitary Lobe Pump
	Sanitary Self Priming Pump
Sanitary Tanks	Storage Tank
	Fermentation Tank
	Mixing Tank
	Warm-keeping Tank
Sanitary Tube	Seamless Tube
	Weldless Tube
Sanitary Gasket	Silicone/EPDM Gasket for Triclamp
	Silicone/EPDM Gasket for Union
	Silicone/EPDM Gasket for Butterfly Valve
	Silicone/EPDM Gasket for Manhole Cover

FAQ
Q1. Are you a trading company or factory?
We are a manufacturing factory.
Q2. Do you have FDA certificate for the materials?
FDA is very important for the food processing machines.
Q3. May I have free sample before ordering?
Yes,our company is very pleased to send to you free sample for quality test as long as freight cost being paid by buyers themselves.
Q4. What's the payment terms?
For small testing orders,we accept Paypal,Western Union,T/T and credit Card.
For mass orders,we accept T/T and L/C.
Q5.How do you control the quality?
Quality control is very important to avoid material mixing and poor quality.We control the quality from beginning to the end.We only have 304 and 316L two different materials.100% inspection on raw material.During production,different materials in different place.After materials are finished,we choose 10% for inspection.If there is 0.1% problem in 10%,then no excuse to go ahead for inspecting 100% of the materials.
Q6.If there is any quality problem,how do you solve it?
We are proud that we never let one customer leave us.We are not 100% perfect,there is some quality problem.We try our best to provide the correct materials in the beginning,so we need less time for quality problem.If there is any quality problem,we take the responsibility.We believe what we are doing together,it will get back tomorrow.If we leave our responsibility,customer will leave us.If we always take our responsibility,we keep our customers with us.
Q7.How long is your delivery time?
For normal production in 7-10days.For bulk order in 15-25days.
Q8.Warranty
One year warranty for all of our stainless steel products.Gaskets are not included due to the different application for customers.
Q9.More questions are appreciated.

---
