Zoomlion Agricultural Equipment TF150 Super Combine Harvester Model 7600mm Cutting Width and 260HP Power Engine

Product Description

Chinese Leading Brand Zoomlion Combine Harvester for Hot Selling:
COMBINE HARVESTER TF150:

Over 1.5m row spacing Feeding capacity 23kg/s 230HP high pressure common rail Yuchai engine 360° in-situ rotation, easy for steering Three-section conveying arm Automatic variable-diameter conveying technology Luxury AC cab, High degree of automation ADVANTAGE INTRODUCTION: * Suitable for working on slope below 10°and field over 1.5m * Three-section bended conveyor, quick release structure that straight and bend type * Front feed roller is driven by two hydraulic motor * Newly added line-keeping system

Product Parameters

Model		Unit	TE150
Dimensions(L*W*H)		mm	11500×2200×3630
Weight		kg	9800
Rail distance		mm	1400
Wheel base		mm	2310
Grounding length		mm	1670
Engine	Model	/	High pressure common rail
	Rated power	kW/rpm	140/2050r/min
	Displacement	L	7
	Emission grade	/	Euro 3
Track width		mm	400
Earthing voltage		kPa	59
Feeding capacity		kg/s	6
Adaptive ridge spacing		mm	≥1100
Adaptive ridge height		mm	0~200
maximum gradability		°	≤20
Operating forward speed		km/h	0~6.65
Qualified rate of cutting height		%	≥90
Root breaking rate		%	≤10
dirt percentage		%	≤8
Total loss rate		%	≤5
Qualified rate of sugarcane section		%	≥93
Fuel consumption per hectare		kg/hm2	190
