High Quality Mother Yarn Split Warping Machine

Product Description

Product Description
AZ328 split warping machine is an automatic warping machine that splits the mother yarn and then warps the beam. the warped beam can be used directly by the warp knitting machine. This is a technological improvement that saves labor costs for customers.
This split warping machine is mostly used for nylon and polyester raw materials. Most tricot machines or double needle bar raschel machines customers require the mother yarn split warping machine.
the warping machine is the equipment used for beam warping. With years of experience and ongoing technology development, A-ZEN split warping machine has become a fair smart one with many advantages combined, such as an easier operation system, intelligent camera detector, auto-saved data, durable PLC system, strong reed needles, and highly-quality measuring speed rollers.

high-quality split warp knitting machine for tricot machine
Warping speed	80-1000m.min
Filament(mother yarn)	20D-140D/8-16F polyester or Polyamide
Bobbin size	400*170mm(outside diameter*height)
Creel	56,64,72,80pcs;2 sides,4 layers arrangement
Beam size	21"*21",30"*21",21" x42",30" x42"
Draft roller	Y-style shape rollers, Driven by the motor,
Warp breakage detector	by camera
Yarn-layer sensor equipment	equipped
Computer control, color touchable	screen, tension auto control

Detailed Photos

Application
The split warping machine is widely used for tricot warp knitting machines and double needle bar warp knitting machines. Mainly used for mother yarn split to mono yarn

FAQ
Q: What is your split warping machine running Speed? A: Our warping machine running speed range is 80~1000m/min

Q: What yarn can be split by your warping machine A: nylon polyester 300/10, 200/10, and so on.

Q: How many cones can your yarn split warping machine have? A: our split warping machine can have cones up to 80 pcs. Each cone's maximum weight can not be over 20kgs

Q: How is your direct split warping machine quality A: We have sold our machines to the international market to many customers and received very good feedback from them.
We largely use renowned and market-tested spare-part brands, to make sure the mechanical and electrical parts are durable

Our Advantages

In-house Sampling Production

In order to test our double needle bar raschel machines' performance, as well as to adjust machine specifications to fit customers' fabric quality, we provide in-house sampling production before the machine delivery. We analyze fabric structure, make a design sketch, and make a record of the knitting process. Our customers could have the access to acknowledge our double needle bar raschel machine performance during real production, but also obtain the knitting production data which is helpful during their mass production.
Local Engineers Installation & Training

We build up serval overseas technical service teams in India, Turkey, Indonesia, Pakistan, Iran, and Egypt. Those well-trained engineers have rich skills and experience for the double needle bar raschel machines installation and production. Our service includes Warping Machine installation, Double-needle Bar Raschel Machines installation, Tricot Machines installation, and Tricot Terry Warp Knitting Machines installation. What's more, our overseas engineers could provide warp knitting basic knowledge and maintenance training for our double needle bar raschel machines. Customers could contact A-ZEN China or A-ZEN overseas office to get this service.
Online Support

All A-ZEN double needle bar raschel machines are equipped with an online service program, and thanks to this, a faster and more accurate service become available. Online Support refers to running faults rectification and machine system checks and protection. So far, we have many successful online support service stories in Turkey, India, Pakistan, and other places, and our customers enjoy a pleasant service that enables their double needle bar raschel machines to be productive.


Routine Maintenance

We send notifications to our double needle bar raschel machine users regularly, especially after the machine works more than two years. Routine maintenance notification plays a vital role when the machine is under poor maintenance conditions. We hope our routine maintenance service could largely avoid production loss because of the inefficient maintenance of the double needle bar raschel machines.

---
