| US$4,852.00-10,000.00 | 1 Piece (MOQ) |
| Model | Picture | Description | Advantage | Qty | ||||||||||||||||||
| Mono 350W | Voltage:36.61V | 22% Transfer Efficiency | 6PCS | |||||||||||||||||||
| Weight:17.13KG Size:1730*900*35mm | 25 Years efficiency warranty 15 Years material | |||||||||||||||||||||
| warranty | ||||||||||||||||||||||
| Combiner | 4T-48V | Wide Range of DC Input | 1PC | |||||||||||||||||||
| Multiple PV strings inputs | Voltage,Thunder And | |||||||||||||||||||||
| max circuit voltage: 500V | Lightning Protection | |||||||||||||||||||||
| 2Years Warranty | ||||||||||||||||||||||
| Solar hybrid | Rated Power:2KW | AC grid charger build in | 1PC | |||||||||||||||||||
| inverter | DC voltage;48V | 2years warranty | ||||||||||||||||||||
| AC Output :110V/220V | USA brand power | |||||||||||||||||||||
| MPPT Solar Charge: 40A | materials | |||||||||||||||||||||
| Optional | 12V150AH | Germany Technology | 4PCS | |||||||||||||||||||
| Battery | Service Life:5-6 Years , | 2Years Warranty | ||||||||||||||||||||
| Size:483*170*219mm | AGM Maintenance-Free | |||||||||||||||||||||
| Gel Battery | ||||||||||||||||||||||
| 48V150AH | Germany Technology | 1PC | ||||||||||||||||||||
| Service Life:10-12 Years , | Including BMS | |||||||||||||||||||||
| Size:442*421*311mm | 3Years Warranty | |||||||||||||||||||||
| Weight:73KG | Lifepo4 Battery | |||||||||||||||||||||
| Bracket | Rooftop / Ground Install | 10years warranty | 1SET | |||||||||||||||||||
| Customized,Including All | ||||||||||||||||||||||
| Parts | ||||||||||||||||||||||
| PV Cables/ | 1)3pcs 16mm2*35CM,4pcs | Professional processed | 1SET | |||||||||||||||||||
| Battery | 16mm2*2M battery cable. | battery cable. | ||||||||||||||||||||
| Cables/ | 2)4mm2 PV cable 100M | 10years warranty | ||||||||||||||||||||
| Connetor | 3)1P 63A Battery switch and | |||||||||||||||||||||
| Model | Picture | Description | Advantage | Qty |
| Mono 350W | Voltage:36V | 21% Transfer Efficiency | 4PCS | |
| Weight:26KG | 25 Years Power Output | |||
| Size:1956*992*40mm | Guarantee | |||
| 10Years Warranty | ||||
| Combiner | 4T-48V | Wide Range of DC Input | 1PC | |
| Multiple PV strings inputs | Voltage,Thunder And | |||
| max circuit voltage: 500V | Lightning Protection | |||
| 2Years Warranty | ||||
| Solar hybrid | Rated Power:1.5KW | AC grid charger build in | 1PC | |
| inverter | DC voltage;48V | 2years warranty | ||
| AC Output :110V/220V | USA brand power | |||
| MPPT Solar Charge: 40A | materials | |||
| Optional | 12V100AH | Germany Technology | 4PCS | |
| Battery | Service Life:6-8 Years , | 2Years Warranty | ||
| Size:483*170*219mm | AGM Maintenance-Free | |||
| Gel Battery | ||||
| 48V100AH | Germany Technology | 1PC | ||
| Service Life:8-10 Years , | 3Years Warranty | |||
| Size:442*421*178mm | Lifepo4 Battery | |||
| Weight:30KG | ||||
| Bracket | Rooftop / Ground Install | 10years warranty | 1SET | |
| Customized,Including All | ||||
| Parts | ||||
| PV Cables/ | 1)1pc 16mm2*35CM battery | Professional processed | 1SET | |
| Battery | cable,4pcs 16mm2*2M | battery cable. | ||
| Cables/ | battery cable. | 10years warranty |
| Model | Picture | Description | Advantage | Qty |
| Mono 400W | Voltage:36V | 21% Transfer Efficiency | 8PCS | |
| Weight:26KG | 25 Years Power Output | |||
| Size:1956*992*40mm | Guarantee | |||
| 10Years Warranty | ||||
| Combiner | 4T-48V | Wide Range of DC Input | 1PC | |
| Multiple PV strings inputs | Voltage,Thunder And | |||
| max circuit voltage: 500V | Lightning Protection | |||
| 2Years Warranty | ||||
| Solar hybrid | Rated Power:3KW | AC grid charger build in | 1PC | |
| inverter | DC voltage:48V | 2years warranty | ||
| AC Output :110V/220V | USA brand power | |||
| MPPT Solar Charge: 60A | materials | |||
| Optional | 12V200AH | Germany Technology | 4PCS | |
| Battery | Service Life:6-8 Years , | 2Years Warranty | ||
| Size:522*240*219mm | AGM Maintenance-Free | |||
| Gel Battery | ||||
| 48V200AH | Germany Technology | 1PC | ||
| Service Life:8-10 Years , | 3Years Warranty | |||
| Size:442*421*222mm | Lifepo4 Battery | |||
| Weight:65KG | ||||
| Bracket | Rooftop / Ground Install | 10years warranty | 1SET | |
| Customized,Including All | ||||
| Parts | ||||
| PV Cables/ | 1)3pcs 16mm2*35CM,2pcs | Professional processed | 1SET | |
| Battery | 16mm2*2M battery | battery cable. | ||
| Cables/ | cable,16mm2 10M cable | 10years warranty | ||
| Connetor | with battery terminal. | |||
| 2)4mm2 PV cable 100M, | ||||
| 3)1P 63A Battery switch |
| 5KW Off Grid Solar Power System Suitable For Daily Power Consumption: >28.8KWH Allowable Max Loads Power: 5KW/7KVA | ||||
| Model | Picture | Description | Advantage | Qty |
| Mono 400W | Voltage:36V Weight:19.41KG Size:1730*1020*35mm | 22% Transfer Efficiency 25 Years efficiency warranty 15 Years material warranty | 12PCS | |
| Combiner | 4T-96V Multiple PV strings inputs max circuit voltage: 500V | Wide Range of DC Input Voltage,Thunder And Lightning Protection 2Years Warranty | 1PC | |
| Solar controller & inverter | Rated Power:5KW DC voltage:96V AC Output :110V/220V MPPT Solar Charge: 60A | AC grid charger build in Japan IGBT material 3Years Warranty | 1PC | |
| Optional Battery | 12V200AH Service Life:5-6 Years , Size:522*240*219mm | Germany Technology 2Years Warranty AGM Maintenance-Free Gel Battery | 8PCS | |
| 96V200AH Service Life:10-12 Years , Size:600*600*1200mm Weight:152KG | Germany Technology Including BMS 3Years Warranty Lifepo4 Battery | 1PC | ||
| Bracket | Rooftop / Ground Install Customized,Including All Parts | 10years warranty | 1SET | |
| PV Cables/ Battery Cables/ Connetor | 1)7pcs 16mm2*35CM,2pcs 16mm2*2M battery cable,20M 16mm2 cable with battery terminal. 2)4mm2 PV cable 100M 3)2P 63A Battery switch and box | Professional processed battery cable. 10years warranty | 1SET | |
| 5KW solar lithium battery system | ||||
| If you want to make it with lithium battery, please kindly recheck the lithium battery system quotation with us. Thanks! | ||||
| Full set: Total volume:3.5CBM Total weight:930KG | ||||
