China Famous Brand Horizontal Directional Drill 160kn-5000kn

US$50,000.00

1 Piece

US$45,000.00

2+ Pieces

Basic Info.

Model NO.

XZ320

Controlling Mode

Artificial

Number of Shaft

Hole Diameter

50-100mm

Automatic Grade

Semiautomatic

Precision

High Precision

Certification

CE, ISO 9001

Condition

New

Dimension

7100*2300*2500mm

Rated Engine Power

140/2300kw/R/Min

Max. Pullback/Thrusting

320/200kn

Max Torque of Driving Head

12000n.M

Driving Head Speed

0-140r/Min

Bore Diameter

400m

Max Backreaming Diameter

800mm

Drill Pipe Length

Drilling Angle

10-20

Overall Weight

10500kg

Transport Package

Container or RO-RO or Bulk Ship

Specification

ISO, CE

Origin

Xuzhou, Jiangsu

HS Code

8430411900

Production Capacity

50000PCS/Year

Product Description

China Famous Brand Horizontal Directional Drill 160kn-5000kn
These kind of horizontal directional drill mainly used under the condition of non-excavating ground surface, laying and replacing various kinds of underground pipes and lines.
The machine features advanced performance, high efficiency, and comfortable operation, and the key parts
all matches international standards. It is the optimal equipment for the construction in the fields of water
supply, gas supply, as well as electricity, telecommunication, heating, and petroleum supply.

Model			XZ280		XZ320
Engine Model			Shangchai D6114ZG		Shangchai D6114ZG
Rated engine power(KW/r/min)			140/2300		140/2300
Max. pullback/thrusting(kN)			280/280		320/200
Max torque of driving head(N.m)			10000		12000
Driving head speed(r/min)			0-120		0-140
Bore diameter(m)			400
Max backreaming diameter(mm)			Ø750		Ø800
Drill pipe length(single)(m)			3		3m
Drill pipe diameter (mm)			Ø73		Ø73
Drilling angle(·)			10-23		10-20
Max flow rate of mud(L/min)			250		320
Max mud pressure(bar)			80		80
Overall weight(kg)			12500		10500
Dimension (mm)	Length	7100		7100
	Width	2260		2300
	Height	2450		2500
