1.Operators are available to walk into the fume hood to operate if need.
2.Large room exhaust system, suitable for large laboratory instruments and equipment.
Model
| FH1200(W)
| FH1500(W)
| FH1800(W)
|
External Size (W*D*H)
| 1200*850*2200mm
| 1500*850*2200mm
| 1800*850*2200mm
|
Internal Size (W*D*H)
| 1000*650*1500mm
| 1300*650*1500mm
| 1600*650*1500mm
|
Max Opening
| 1150mm
|
Exhaust Airflow Volume
| 1150m3/h
| 1500m3/h
| 1850m3/h
|
Inflow Air Velocity
| ≥0.4m/s
|
Noise
| 62dB
|
Vibration
| XYZ direct ≤4μm
|
Illumination
| ≥800Lux
|
Fluorescent Lamp
| 21W*2
| 28W*2
| 40W*2
|
Power Supply
| AC220V±10%, 50/60Hz;110 V±10%, 60Hz
|
Consumption
| 400W
| 500W
| 500W
|
Front Window
| Manual, Toughened glass, Anti UV
|
Material
| Exterior
| 1.2mm cold-rolled steel with bacteria powder coating.
|
Interior
| High grade melamine board with good acid and alkali resistance function
|
Standard Accessory
| Blower( External) ,Fluorescent lamp, Water tap, Gas tap, PP cup sink, Remote control water valve, Remote control gas valve, Waterproof sockets * 4. ? 300mm PVC Duct
|
Sockets
| Total load of 4 waterproof sockets: ≤500W
|
Package Size(W*D*H)
| 1410*1050*2430mm
| 1710*1050*2430mm
| 2010*1050*2430mm
|
Exhaust Blower
| 970*810*580mm
| 970*810*580mm
| 970*810*580mm
|
