Fully Continuous Waste Tyre Pyrolysis Plant with EU Emission Standard

Product Description

Product Description Fully continuous waste tyre and plastic pyrolysis plant adopts automatic feeding and discharge system, Q345 boiler steel plate as material for rotated reactor. Oil output can reach 50%. Capacity from 15T to 100T. After
couple of hours, Syn gas from pyrolysis generated and burn to supply energy to support the pyrolysis procedure by hot air system. Pyrolysis oil cleaned in gas treatment system and then inserted to oil distillation system, which can make it be clean diesel and petrol. Carbon black and steel wire will be separated and collected at the end of the system. This is the most advanced technology, energy saving and environmental friendly.
Plant Specification

Item	Type	XFLJ--SL-15	XFLJ--SL-30
Capacity/24h		15T	30T
Working temp.		≤650°
Fuel		Fuel oil, natural gas, lpg
Heating way		Hot air circulation heating
Fuel request		Waste plastic, medical waste and household waste
Working pressure		Normal pressure
Inflaming retarding way		Nitrogen purging
Consumption		200 kg	200 kg
Size		14000 × 2400 × 4000(mm)	28000 × 2400 × 4000(mm)×2
Total power		90 kw	170 kw
Power consumption		80 kw/h	150 kw/h
Floor space		40000 mm × 4000 mm	40000 mm × 9000 mm
Highest point of installation		7000 mm	7000 mm

Pyrolysis Pprocedure
Workshop show
Project show

---
