2025 Bcmc Bcdm-1800 Single Head Bridge Stone Polishing Machine with Fickert or Frankfurt Head for Stone Quartz Slabs Surface Polishing

US$14,500.00-16,500.00 1 Set (MOQ)

Basic Info.

Model NO.
BCDM-1800
Type
Stone Polishing Machine
Control
CNC
Automation
Automatic
Precision
Precision
Application
Ceramics, Glass, Concrete Curb, Granite, Marble, Stone Industry
Type for Grinding Machine
Disc Grinding Machine
Grinding Machine Type
Single Head Polishing Machine
Grinding Method
Dry Grind
Certification
ISO, CE
Condition
New
Usage
Ceramics, Granite, Marble, Quartz
Source Voltage
380V
Cutting Ability
High Speed
Overall Weight
7000 Kg
Work Bench Specifications
3200 X 2000
Control System
PLC
Transport Package
Plastic Packing
Specification
6000 x 5000 x 2800 mm
Trademark
BCMC
Origin
Putian, Fujian, China
HS Code
8460902000
Production Capacity
50 Pieces/Month

Product Description


BCMC Machinery BCDM-1800 is mainly used for granite, marble polishing. Able to assemble frankfurt head or fickert head for different kind of stone processing. With advantages such as rational construction, steady movement, high accuracy, convenient installation and easy maintenance. Smoothly and continuous polishing. Good processing effect.
Main Features: Controlled by PLC, operated expediently, accurately and stably. Working table can tilt at 85 degrees for easy loading slabs. Can hold two types polishing head for granite and marble. Able to dealing with different kind of stone type processing for polishing head changing
Parameters:
Configuration Power of main motor kw 11
Working platform dimensions mm 3200 x 2000
Air pressure required Mpa 0.3 - 0.5
Main Performance Parameters Max. processing dimensions mm 3200 x 3200 x 60
Working platform tilting degree n° 0-85
R.P.M. of polishing head r/min 550
X axis feeding speed mm/min 5300
Y axis feeding speed mm/min 4000
Air consumption m3/min 0.15 - 0.3
Water consumption m3/h 4

Measurement		 Gross weight kg 7000
Dimension (L x W x H) mm 6000 x 5000 x 2800

Application:
* Stone polishing and buffing
* Slab polishing
* Slabs Surface Polish
