110 Degree Wireless PIR Detector with Long Battery Life

US$6.00

1-99 Pieces

US$4.80

100+ Pieces

Basic Info.

Model NO.

SR-615R

Application

Video Store and Bookstore, Warehouse, Shopping Arcade, Supermarket, Garment Store, Jewelry Store

Detection Signal

Radio Frequency RF

Certification

CE, ISO, RoHS

Frequency

315MHz or 433MHz

Detect Distance

12 Meter

Color

White

Certificate

Ce Approval

Type for System

Wireless Burglar Alarm System

Name

110 Degree Wireless PIR Detector with Long Battery

Transport Package

Carton

Specification

ABS

Trademark

SUMRING

Origin

China

HS Code

8531901000

Production Capacity

50000 PCS/Month

Product Description

110 degree wireless PIR Detector with long battery life

Main features:
PIR Detector: Wireless Wide Angle PIR Detector SR-615R
wireless transmitting digital signal
low power indication
ASIC adopted
Automatic temperature compensation
Low power consumption, long battery life
SMT adopted, anti-RFI & anti-EMI

Technical specification:

Operating voltage	9V battery
Standby current	less than 25uA
Alarm current	less than 15mA
Operating temp	-10 to +50 degrees
Installation mode	wall mounted
Installation height	about 2m
Detecting distance	12m
Detecting angle	110 degrees
Transmitting freq	315MHz or 433MHz
Transmitting distance	more than 200m (in the open area)
Dimension	1075945mm

Product Pictures
