0.05 Moly Sheet/ Cold Rolled Molybdenum Round Disc Sheet Plate, Polished Tungsten Sheet / Molybdenum Strip Plate Sheet

Product Description

Pure Molybdenum sheet and Molybdenum lanthanum sheet plate
Molybdenum sheet/plate/foil/strip
specification:
1) Purity≥99.95%
2) Density:10.2g/cm3
3) Size: Thickness 0.05-50.0mm Width 20-800mm Length 100-3000mm or as your need
4) Grade:Mo1/MoLa/TZM
5) Processing:cold rolled, Stress relief annealing, Hot rolled
6) Surface: polished, washed, ground, grinding.
Molybdenum sheet/plate/foil/strip-Mo1/MoLa/TZM
99.95% Molybdenum Sheet, Molybdenum Strip 0.3mm 0.5mm Thickness
1. Purity: Mo>= 99.95%
2. Standard: GB/T 4182 or ASTM
3. Property specification
1) high melting point, high strength,
2) smooth and clean surface,
3) good conductions, small linear expansion coefficient and good heat-resistance.
Molybdenum foil, Molybdenum MoCu alloy sheet and molybdenum TZM Mola sheet/wafer/disk
Molybdenum discs/wafer/washer/round circle
specification:
1) Grade: Mocu
2) Density: 9.8-10.2g/cm3
3) Size: 0.05-100mm(thickness)*5-500mm(diameter) or as your need
4) Flatness tolerance:<4um
5) Roughness:Ra1.6-Ra0.8
6) Surface: polished, ground.
Molybdenum copper alloy forged rods Molybdenum contents 50%-85%
Mo-Cu composites has lower density, its thermal expansion coefficient and thermal conductivity can be adjusted to match many different materials.
MoCu alloy physical Properties of Major Products

Material	Wt% Molybdenum Content	Wt% Copper Content	g/ Density at 20ºC	W/M.K Thermal conductivity at 25ºC	(/k) Coefficient of thermal expansion at 20ºC
Mo85Cu15	851	Balance	10	160-180	6.8
Mo80Cu20	801	Balance	9.9	170-190	7.7
Mo70Cu30	701	Balance	9.8	180-200	9.1
Mo60Cu40	601	Balance	9.66	210-250	10.3
Mo50Cu50	500.2	Balance	9.54	230-270	11.5

Features of Molybdenum copper alloy:
1)Large sized sheets available ( we can supply as the customers' need)
2)More easily to be stamped into components than CMC
3)Very strong interface bonding which can repeatedly resist 850ºC heat shock
4)Higher thermal conductivity and lower cost
Molybdenum copper alloy application:
molybdenum copper used in spaceflight fields.
Molybdenum copper alloy has more excellent performances, so can be used as high temperature part of rockets and missiles. This alloy has high thermal conductivity, thermal expansion, high melting point, and the good mechanical ability, all of these reasons, which make the molybdenum copper can be used in the spaceflight fields.
Mola and pure molybdenum discs/wafer/washer/sheet
Thinner Molybdenum Sheet Molybdenum Foil Mocu Sheet Tzm Molybdenum Sheet
1. Purity: Mo>= 99.95%
2. Standard: GB/T 4182 or ASTM
3. Property specification
1) high melting point, high strength,
2) smooth and clean surface,
3) good conductions, small linear expansion coefficient and good heat-resistance

	Thickness (mm)	Width(mm)	Length(mm)	Surface	Rolled condition
Molybdenum Plate	8.0-16.0	10-1000	10-1000	Alkali washed	Hot rolled
	3.0-8.0	10-1000	10-1000		Hot rolled
Molybdenum sheet	1.5-3.0	10-1000	10-2500	Acid cleaning	Coled rolled
	0.5-1.5	10-1000	10-2500		Cold rolled
	0.2-0.5	10-1000	10-2500		Cold rolled

Our main products:
Molybdenum Products
Molybdenum rods/ Molybdenum plate /Molybdenum sheet
Molybdenum wire/ alloy Molybdenum wire/ Moly wire for EDM
Molybdenum electrode/molybdenum disk/Molybdenum boat/ Molybdenum Crucible/Molybdenum tube
Tungsten Products
Tungsten rods/ Tungsten plate/ Tungsten sheet
Tungsten wire/ Tungsten electrode
Tungsten crucible /Tungsten boat/ Tungsten tube
Other specail shape/part
Alloy Products
TZM Products/MoLa products, WC, Ti, Ta, Ni, etc.
WNiFe / WniCu Product/ Alloy ball/WC-Co
Tungsten fishing products
Tungsten bead, tungsten alloy shot for hunting, tungsten metal material
More information about us:
We promise you -- The advantage of us: 1) products quality, with many years of producing experience 2) low price in the market, and factory direct sales. 3) the whole production line from powder to finished products, top and steady quality assured
4) good packing for safe exprot delivery, and fast manufacturing time 5) fast delivery and best after-sale service.

---
