Door Lamination Machine: OSB MDF HDF Chipbaord Particleboard Production Machinery Sanding Machines

US$6,000.00-100,000.00 1 set (MOQ)

Basic Info.

Model NO.
MH-OSB400
Product Type
OSB Production Line
Automatic Grade
Semiautomatic
Power Source
Electric
Screw Design
Double-Screw
Certification
CE, ISO
Condition
New
Customized
Customized
Name
Pb Production Line
Machine Included
The Full Complete Production Line
End Product
Particle Board
Particle Board Size
4*8feet or Customized
Panel Thickness
10-30mm
Daily Capacity
100-400cbm
Yearly Capacity
30000-180000cbm
Machine Color
Be Customized
Transport Package
None
Specification
4*8feet or customized
Trademark
MINGHUNG
Origin
Linyi City, China
HS Code
846592
Production Capacity
10 Sets /Year

Packaging & Delivery

Package Size
600.00cm * 230.00cm * 260.00cm
Package Gross Weight
10000.000kg

Product Description


Product Description
Drum Chipper
Inlet size 240*750mm(H*W)
Blade quantity 2pcs
Knife roll diameter 800mm
Power 132kw

Triple Pass Drying Machine
Cpacity 10000kg/h
Original moisture ≤80%
End moisture 2%
Power 440kw

Forming machine
Surface forming machine 2 sets
Capacity 2 *45m3/h
Core forming machine 1 sets
Capacity 65m3/h
Forming width 1300mm
Forming thickness 30-120mm

Continuous press
Convey speed 10-30m/min
Working height 1250mm
Belt width 1500mm
Power 75kw

Hot press
Pressure 1200 ton
Hot plate size 2650*1680*120mm
Layers 22
Heating medium Oil
Heating temperature ≤180ºC
Closing time 10s

Edge trimming saw
Suitable final board Particle board, MDF, OSB, Plywood
Panel size 4*8feet or be customized
Working way Automatic
Panel thickness max 60mm
Weight 15to


Sanding machine
Max sanding width 1300mm
Sanding thickness 3-50mm
Sanding belt size 1350*2800mm


Working Process
