u Automatic air inlet design, to ensure efficiency and test accuracy at the same time;
u The instrument actually measures the up stream volume, so the test result is more accurate;
u Automatic control of air intake level, with a smooth and safe air intake, to ensure the service life of filter element;
Power Supply
| 100 – 260 VAC, 50HZ, 120W ；
|
Operation pressure
| 100-8000mbar (115psi) ;
|
Unit
| mbar
|
Operation Condition
| Ambient Temperature：+5℃ ~ +40℃；Relative Humidity：10-80%
|
Dimension（mm）
| 400（Depth）*240（Width）*270（Height1）*220(Height2)
|
Test Function
| Manual Bubble point Test；Basic Bubble Point Test；Extensive Bubble Point Test；Diffusion Flow Test；Water Immersion Test；
|
Test Accuracy
| Upstream Volume：± 4%；Bubble Point：≤± 50mbar ；Diffusion Flow Test：≤± 4% ；Water Immersion Test：≤± 0.05ml
|
Test Scope
| Bubble Point ：590-6900mbar Diffusion Flow Speed：1-180ml/min WI：0.01-30ml/min
|
Applied Range
| Symmetric and asymmetric membrane test, needle filter, filter bag, flat filter, filter cartridge (3 core within 20 inches)
|
Print Function
| Built-in printer；
|
Historical Records
| 500 sets；
|
Display Screen
| 5.7″TFT，Single color；
|
Serial Connection
| RS232；
|
Language
| Chinese/English；
|
Work Mode
| Online/Offline；
|
Applicable Environment
| Above B level；
|
Weight
| 7.5KG；
|
