High Quality Charcoal briquette machine/coal powder briquetting machine
Contact person:Ms Nina
Phone:0086-13673629307
Skype:taizy0407
Tel:0086-371-86660712
Fax:0086-371-86660713
Brief introduction of coal briquette machine:
The coal powder briquetting machine is widely used to make powder material like charcoal powder, coal powder into coal briquette.
Raw material size should be smaller than 5mm and the best moisture for briquetting is 10-15%.the shape can be round,oval, pillow,rectangle,square shapes.The finished products' surface is very smooth, also the pressure and density can be adjustable.
Raw materials of coal briquette machine:
It can press different powder into different shape. Such as, coal powder, charcoal powder, metallic powder (FeSi powder), iron scale, iron sludge,
precipitator dust, iron concentrate, raw material powder, manganese ore fines, slime peat, fireproof material, desulfurized gypsum can be press into round and pillow shape.
Features of coal briquette machine:
Our machine has features of high productivity, significant energy-saving, easy to use, safe, reliable, easy to maintain, use low-cost, is the ideal coal processing equipment.
Parameter of coal briquette machine:
Model
| Output (T/H)
| Annual output
| Power(kw)
|
TZ-290
| 2Ton
| 5000ton
| 5.5KW
|
TZ-360
| 4 Ton
| 10000Ton
| 7.5 KW
|
TZ-400
| 6 Ton
| 15000 Ton
| 11 KW
|
TZ-430
| 7 Ton
| 17000 Ton
| 11 KW
|
TZ-450
| 8 Ton
| 20000 Ton
| 15 KW
|
TZ-500
| 10 Ton
| 25000 Ton
| 18.5 KW
|
TZ-600
| 12 Ton
| 30000 Ton
| 22 KW
|
TZ-650
| 14 Ton
| 35000 Ton
| 30 KW
|
TZ-750
| 17 Ton
| 40000 Ton
| 37 KW
|
TZ-800
| 20 Ton
| 50000 Ton
| 45 KW
|
TZ-1200
| 40 Ton
| 100000 Ton
| 75 KW
|
Photo show of coal briquette machine:
Working Principle of coal briquette machine:
This series of briquette machine will pass the power on to the two pressure roller through the reducer.
The two sides and roll rotation, in both the rotating roll,Natural materials to enter the ball roll mode, with the roll rotation,
material pressure on a small become larger, When the material to the two rollers rotating line contact point, the pressure of materials has reached the peak. T
remendous pressure in the role of line, the materials become a finished product from the powder ball.
Production line of coal briquette machine:
Besides the coal briquette machine, we have the equipments for the whole production line in store for you, such as the Coal Crusher, Binder Mixer, Double -shaft Mixer, Belt Conveyor, Auto Feeder, etc. The following are the brief introduction of the procedures, please have a check:
1. You need to crush the coal into powder material by Coal Crusher.
2.Make liquid binder for increasing the hardness of the coal powder by Binder Mixer.
3.Mix the liquid binder with the coal powder by the Double-shaft Mixer.
4.Feed the material into Coal Briquette Machine for producing coal briquettes.
5. Dry the coal briquettes duo to the liquid binder by Box-type Dryer or just under the sunshine if it is strong enough
