Xgj700p Wood Pellet Machine with High Sales Volume and Good Reputation

Product Description

Product Description
XGJ700P wood pellet machine with high sales volume and good reputation
XGJ series vertical ring die pellet machine is different from other horizontal ring die machine, this machine with vertical structure, easy for biomass materials feeding, big pressure, big capacity and working stable. It is the high efficiency equipment for biomass pellet making.
This equipment is good at press low adhesive and hard molding materials, such as press the rice husk, hard wood sawdust, sunflower seeds husk, peanut shell, wood bark and other wood waste, it also can press different kind of straw and agriculture waste. This pellet machine is widely using in biomass pellet making industry and other pellet forming industry.

Our Advantages
1. Vertical ring die structure, feeding vertically, easy heating dissipation, long time running continually.
2. Ring die fixed, the roller rotates in the ring die, so no deflection, no shaking, machine running more stably.
3. Double-layer stainless steel ring die, up and down side. One ring die can be using 2 times by turn it over. Cut down operating costs.
4. With gear box lubricating system and the roller bearing auto-lubricating system, the machine can operating continuity. (Can 24 hours no stop working)
5. Whole based as gearbox, inside gears size big, and gear modulus increased, make the gearbox strong and working stable. We give 3-year guarantee for this type of gearbox. Product Parameters

Model	Power (kw)	Capacity(kgs/h)	Weight(kgs)	Dimension(mm)
XGJ560	90+1.5+0.37+1.5	1000-1500	5100	2600x1300x2300
XGJ560P	132+1.5+0.37+1.5	1500-2000	5200	2600x1250x1600
XGJ700P	160+3+0.37 +0.55+3	2000-3000	6200	2600x1600x1950
XGJ850	220+3+0.37(0.55)+2.2	2000-3000	8200	3100x1600x2000
XGJ850P	220+3+0.37(0.55)+2.2	2500-3500	9600	3300x1400x3100

Production photos

Detailed Photos
Electric control cabinet (soft start device) mold cooling fan
Sucessful Case

Packaging & Shipping

For the biomass pellet making machines / complete pellet production line loading, we have rich experence, we know which is the best way to loading them into container and also keep them safty when transfer. Want more Information
I'm Clara from Shandong Dexi Machine Co., Ltd,We are professional supplier for biomass pellets machines and related equipment,such as wood /feed/organic fertilizer pellet machines, crusher, hammer mill, auxiliary equipment for pellet making and complete pellet production line.
Our company is established by a dynamic team which all has 20 years of experience in pellet machine trade and have strategic cooperation with plant, so we could guarantee the supply with good price and quality.
Any more info you need for the equipment,please feel free to contact us!
Send me an inquiry and I provide you with professional services!

---
