Product Description Arm Roll Garbage Bin Cleaner (Side-Lifting Garbage Truck):
Mechanism: Equipped with a hydraulically operated arm that can lift and tip bins to empty the contents into the truck's collection hopper. Efficiency: Allows for the emptying of bins without the need for manual labor, increasing the speed and efficiency of waste collection. Versatility: Can handle a variety of binsizes and types, making it suitable for different environments such as streets, commercial areas, and residential complexes. Hygiene: Reduces the exposure of waste collectors to potentially hazardous waste, improving working conditions. Operation: The arm can be controlled from the truck's cab, allowing the operator to safely and accurately empty bins. Detailed Photos
| Cabin | Driving type 4x2 |
| H5 Cabin with two seats,with A/C. Right Hand Driven. 70° hydraulically tillable to the front as attached photo for ref. |
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 8000x2500x3500 |
| Wheel base (mm) | 4200 |
| Wheel track (front/rear) (mm) | 1980/1860 |
| Approach/Departure angle(°) | 24/15 |
| Weight in KGS | Tare Weight | 8000 |
| Loading Capacity | 10000 |
| Front axles loading capacity | 1×6000 |
| Rear axles loading capacity | 1x12000 |
| Max. driving speed(km/h) | 90 |
| Engine | Brand | YUCHAI |
| Model | YC6J220-33 |
| Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling |
| Horse Power(HP) | 220 HP |
| Emission standard | Euro 3 |
| Gearbox | DC6J65TC, 6 forwards &1 reverse |
| Clutch | Reinforced diaphragm clutch, diameter 430mm |
| Steering Gear | ZF steering, hydraulic steering with power assistance |
| Fuel tank (L) | 300 L |
| Tire | 10.00R20 tires with one spare, totally 7 pcs. |
| Swing arm system with cargo box |
| l Garbage cargo box :10CBM , Carbon steel material , underground type or aboveground type can be optional. |
| l PTO motivated hydraulic system, two hydraulic cylinders with lifting arm and two hydraulic cylinders with landing leg |
| l Swing arm maximum pivot angle 145 ; hoisting time 30s ; Unloading time 50s. |
