Stainless Steel Titanium Ti Gr1 Gr2 Kettle Industrial Bioreactor Mixer Continuous Stirring Agitated Reaction Tank Chemical Reactor

Product Description

Agitating Reactor

Product Description
The reactor is a comprehensive reaction vessel, and the design of the reactor structure, function and configuration accessories according to the reaction conditions. From the beginning of feeding-reaction-discharging, pre-set reaction steps can be completed with a high degree of automation, and important parameters such as temperature, pressure, mechanical control (stirring, blasting, etc.), reactant/product concentration in the reaction process can be strictly controlled. Its structure is generally composed of kettle body, transmission device, stirring device, heating device, cooling device and sealing device.
Reactor materials generally include carbon-manganese steel, stainless steel, zirconium, nickel-based (Hastelloy, Monel) alloys and other composite materials. The reactor can be made of stainless steel materials such as SUS304 and SUS316L. The agitator has anchor type, frame type, paddle type, turbine type, scraper type, combined type, and the rotating mechanism can adopt cycloid pin wheel reducer, stepless variable speed reducer or frequency conversion speed regulation, etc., which can meet the special reaction requirements of various materials. The sealing device can adopt mechanical seal, packing seal and other sealing structures. Heating, cooling can use jacket, half tube, coil, Miller plate and other structures, heating methods are: steam, electric heating, heat transfer oil, to meet the acid resistance, high temperature resistance, wear resistance, corrosion resistance and other different working environment process needs, according to the user process requirements for design, manufacturing.
Reactor is widely used in petroleum, chemical, banana, pesticide, dyes, medicine, food, used to complete vulcanization, hydrogenation, hydrocarbonization, polymerization, condensation and other processes of pressure vessels, such as reactors, reaction pots, decomposition kettles, etc.

Types of Reactor:
Various speed Tri shaft Mixing SS Reactor.
Pharmaceutical Chemical SS Reactor.
Polishing Electric Heating Mixing SS jacket tanks.
SS Reactor With Agitator for input conduction oil.
Reactor Coil Heating With lifting lugs or supporting legs.
High pressure SS Reactor / Heating Jacketed reactor.
Electric power SS Composite Reactor / Composite mixer.
SS Jacketed reactor with stirring stirring device.
CE Electric Heating SS Reactor /chemical reactor.
Corrosion resistant Pharmaceutical SS Reactor.
Paint use electrical heating Reactor/500L-5000L SS tanks.
Industrial Jacketed SS reactor volume of 500L-20000L.
Engineering Cases

Related Products
Storage Tank Column Heat Exchanger
Company Profile
Changzhou General Equipment Technology Co., Ltd. is located in LiYang city, a famous scenic and tourist city in JiangSu Province. It is a high-tech equipment manufacturing enterprise . The company is located in the local High-tech Machinery Industrial Park, with very convenient transportation.
The company covers an area of 70,000 square meters, plant area of 50,000 square meters, nearly 100 employees. The company has high-end processing equipment & testing equipment; It has D1 and D2 pressure vessel design qualifications and A2 pressure vessel manufacturing qualifications.Our main products are including Jet Mill Micronizer, Mixer, Granulator and Dryer, Chemical Equipment: Reactor, Heat Exchanger, Column, Tank and Environmental Protection Equipment, etc .
We provide technology research and development, process design, equipment manufacturing, installation and commissioning, project contracting and other comprehensive services. Our products are quite widely applied in the industry of petrochemical industry, Pharmaceutical , Agricultural Chemistry, New Energy, thermal power, steel smelting, Environmental Protection and other Service.Our customers are from the domestic and overseas markets, product quality and fantastic service are deeply praised by customers and partners.
We adhere to the concept of "Scientific Management, Advanced Technology, Quality Priority & Win-Win Cooperation", pursue the enterprise purpose of "Market by Quality, Win customers by Reputation, and seek development by Science & Technology", carry forward the enterprise culture, deepen the enterprise management, enhance the enterprise image, actively create new high-quality products, to provide customers with the superior quality.
Sincerely welcome all customers to visit our company for guidance and cooperation, let's make a better future together.
