ASME Standard LPG Tank Trailer 50cbm LPG Tank Trailer

Product Description

ASME standard LPG tank trailer 50CBM LPG tank trailer
Specifications
1, Adopts Ellipse shape of the End Plate
2, Big capacity, good partner of your business
3, LPG Semi trailer LPG gas trailer LPG tank trailer LPG tanker trailer.
4, Good quality with competitive price, it can be accepted.
5, Our LPG Products: LPG Storage tank, LPG Tank Truck, LPG Tank Trailer, LPG Skid Station.
6, The capacity of the tank we can supply: 5-120CBM
7, Trailer Axle: 2 Axle, 3 Axle, 4 Axle.
8, Certification: ISO9001 CCC,SGS,ASME lpg gas trailer liquid gas trailer propane gas trailer lpg tank trailer lpg tank gas trailer.
Technique parameters

Description	ASME Standard LPG Tank Trailer 50cbm LPG Tank Trailer
Condition	New condition/LHD&RHD
Semi trailer	Curb weight(kg)		15300
	G.V.W.(kg)		36132
	Wheelbase(mm)		6800+1310+1310
	External Dimensions(mm)		12740*2480*3800
Tank	Capacity(m³)		50
	Design pressure(MPa)		1.61
	Filling medium		LPG
	Tank material		Q345R/Q370R
	Corrosion allowance(mm)		1.0
	Hydraulic test pressure(Mpa)		1.0
	Thickness of Shell (mm)		12.0
	Thickness of Endplate (mm)		12.0
Main part of Tank	Item	Specification		Quantity(pc)
	Drain hole	DN50		1
	Liquid line	DN50		2
	Manhole	DN450/DN500		1
	Empty valve	DN50		1
	Horizontal liquid level gauge Interface	DN25		1
	Pressure meter Interface	M20x1.5		2
	Gas line	DN50/DN25		1
	Safe valve	DN50		2
Standard configuration	-3 axles with BPW bridge (13T),12R22.5 12PR(13 pcs) -JOST king pin,JOST leg(25T),mechanic liquid level meters -Double pressure meter,double thermometer,double emergency cutting valve -Four ball valve,double safe valve,two tool boxes, single outlet -Double loading and unloading system, 2 sets 9kg fire extinguishers type ABC -1 set 2kg fire extinguisher type CO2,3 sets danger sign plate -2 sets orange numbered plate.
Remarks	Aluminum sunshade protection, Tank is fitted with a sun shield of 2mm aluminum allow (3003) and 50mm heat insulation meterial, prepainted white (equivalent) RAL 9010 covered angle approximately 120°.

LPG trailer brief 1)Designing pressure: 1.61MPa Designing temperature: -20C-50C
2)The various types LPG tanker is researched and manufactured by stress analysis design and has obvious advantage of large capacity. Light weight and high efficiency.
3)We inspect the quality of product strictly, ensure that A and B type of welding seam pass the examination of level two radiographic test, C and D type of welding seam pass the examination of level one radiographic test.
4)There are domestic or imported safety accessories with high quality, its matching is complete.
5)The anticorrosion coating of LPG tanker adopt the following process, sandblast, spray painting, purging and so on
Products images
Strict Manufacturing Procedures
Why choose us ChengLi Special Automobile Co.,LTD.
In the special vehicle circle, has developed into the biggest professional special vehicle manufacturer of central China starting from scratch since 2004
There are totally 8,000 workers in factory and can supply 800 types of trucks. In 2014, our total sales revenue reach $300 million.
Over the past 11 years, our group made a great achievements in the special vehicle circle, our products have been sold to many country around the world, such as Nigeria, Vietnam, Garner, Uganda, Singapore, Malaysia, Congo, Cameroon etc.
There're many type trucks in our company, because we built up a long cooperate relationship with many famous brand chassis manufacturer, such as Sinotruk, Dongfeng, Foton, Shacman, JAC, JMC, ISUZU, FAW etc.
Look forward to the future, we are confident, we truct we can do better! We will pay more attention to the quality of the products, that's what we always do!

Customised Truck & Trailer Solutions to Meet Your Requirements
Our main products:
1. Dump Truck / Tipper Truck
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck mounted crane
4. Oil Tank Truck / Fuel Tanker Truck
5. Water truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
Ms. Janie Chen
Sales Representative
Chengli Special Automobile Co., Ltd
Factory: Chengli Automobile Industry Park,Suizhou, Hubei, China
Office: Block 2, Fengzeyuan Villa, Dongxihu District, Wuhan City, Hubei Province, China.
Mobile: +86-18771991406
Tel&Fax: +86-27-83796298
Web: https://chenglitruck.en.made-in-china.com
