Turret Milling Machine Xn6330h X6330h Xs6330h

US$3,000.00-4,000.00 1 Piece (MOQ)

Basic Info.

Model NO.

XN6330H X6330H XS6330H

Type

Knee Type Milling Machine

Object

Metal

Structure

Ram

Milling Cutter Type

Vertical Milling Cutter

Milling Cutter Structure

Indexable Type

Controlling Mode

Artificial

Automatic Grade

Manual

Precision

High Precision

Certification

CE, RoHS, ISO 9001

Condition

New

Table Size

254X1370mm

Long Travel(mm)

950mm

Cross Travel(mm)

420mm

Vertical Travel(mm)

420mm

Motor

3.75kw

Transport Package

Plywood Case

Specification

1600kgs

Trademark

HOYONG-TRD

Origin

Shandong, China

HS Code

84581900

Production Capacity

10 PCS/Month

Product Description

MILLING MACHINE FEATURES:
The machine is suitable for machinery, light industry, instrument, motor, electrical appliance and moulds, and widely used in machining of plane and arbitrary angle plane, and slotting, drilling, reaming, boring etc.
SPECIFICATIONS:

SPECIFICATION		UNIT	XN6330H	X6330H			XS6330H
Table size		mm	300X1300	300X1370		300X1500	300X1370	300X1500
Table longitudinal travel		mm	845			1000	880	1000
Table cross travel		mm	385				380
Table vertical travel		mm	435
Table longitudinal feed rate		mm/min	0-3500 Servo motor	---
Table cross feed rate		mm/min
Knee vertical feed speed		mm/min	900
V	Motor power	HP	5HP				Standard:3HP/Optional:5HP
	Spindle speed	rpm	Standard:16steps, 50HZ: 65-4500/60HZ:80-5440 Optional:variable speed: 65-3750
	Spindle taper		ISO40				Standard:R8/Optional:ISO40
	Quill travel	mm	127
	Quill feed	mm/r	0.04/0.08/0.15
	Head rotating		R/L 90°				R/L 90°, B/F 45°
	Distance from spindle nose to table surface	mm	115-545
H	Motor power	HP	5HP
	Spindle speed	rpm	50HZ: 45/80/165/260/500/980 60HZ: 55/100/200/315/600/1180
	Spindle taper		ISO40
	Distance from spindle to table	mm	-20-410
	Distance from spindle to arm	mm	183
Arm travel		mm	480
Arm rotating angle			360°
Net weight		kg	1900		1950		1680	1730
Package size		m	1.8X1.5X2.2		1.8X1.8X2.2		1.8X1.6X2.2	1.8X1.8X2.2
