| US$23.00-63.00 | 1 Piece (MOQ) |
| Nominal diameter | mm (in.) | 389(15) |
| Nominal impedance | Ω | 8 |
| Minimum impedance | Ω | 6.7 |
| Program power (1) | W | 2400 |
| AES Power rating(2) | W | 1200 |
| Sensitivity (3) | dB | 97.5 |
| Frequency range | Hz | 40 ~ 1000 |
| Voice coil diameter | mm (in.) | 100(4) |
| Chassis material | Aluminium | |
| Magnet material | Ferrite | |
| Magnet dimensions (ODxIDxh) | mm | 220 x 110 x 25 2pcs |
| Coil material | SV | |
| Former material | Glass Fiber | |
| Xmax(4) | mm | 12.5 |
| Xmech(5) | mm | 18 |
| Gap height | mm | 10 |
| Voice coil Wingding height | mm | 30 |
| DC resistance | Re | Ohm | 6 |
| Resonance frequency | Fs | Hz | 40 |
| Moving mass | Mms | g | 183 |
| Compliance | Cms | mm/N | 0.10 |
| Force factor | BL | N/A | 28.3 |
| Mechanical Q-factor | Qms | 6.61 | |
| Electrical Q-factor | Qes | 0.4 | |
| Total Q-factor | Qts | 0.37 | |
| Equivalent air volume | Vas | I | 121 |
| Voice coil Inductance | Le | mH | 1.8 |
| Diaphragm area | Sd | cm² | 880 |
| Reference efficiency | Eta 0 | % | 2.5 |
| Net weight | Kg | 15 |
| Multipack size (1) (W x D x H) | mm | 410 x 410 x 230 |
| Multipack weight | Kg | 16.2 |
