Alloy Wheel Rim Repair CNC Lathe Taian Crystal Wheel Repair Machine Wrm26h Awr2840 PC

Product Description

The currency exchange rate fluctuates greatly, please consult customer service for the best price.
Our purpose build alloy wheel lathe incarcerates a user friendly multi-touch interface
for simplified probing and cutting processes. With full digital optimization build directly
into the interface, there is no need of a separated computer system to house the software,
making this our best ALL IN ONE solution for repairing diamond cut alloy wheels.
Product Display
Wheel Repair Lathe Advantages
1. Cuts wheel up to 27''.
2. 17 inch interface touchscreen.
3. With CE, SGS, ISO, BV certificates.
4. Automatic ruby probe system.
5. Self-developed optimization software.
6. Free Training video and manual.
7. 7x24 hours technology support.
8. 2 USB interface.
9. High efficiency and economic.
10. Two-year warranty.
11. Free factory hand-to-hand training.
12. Agencies in UK, Germany, Poland, Netherlands, Australia etc.

Alloy Wheel Repair Lathe : Specifications

ITEMS		WRM26H-PC
Max. swig over bed (mm)(inch)		Φ720(28')
Max. Diameter of alloy wheel(mm) (inch)		Φ660(27')
Max. Stroke of the X-axis(mm)		350
Max. Stroke of the Z-axis (mm)		850
Width of the rail (mm)		330
Length of the rail (mm)		1300
Size of the three-jaw chuck (inch)		13'
Range of spindle speed (RPM)		50-2000
Spindle speed control		Automatic
Spindle bore (mm)		Φ60
Taper of spindle bore		MT6
Taper of spindle nose		A2-8
Adjustable stroke of carrier in X direction		100mm
Max. size of tool post		25×25mm
Stations of tool carrier		4 position
Min. setting unit of motor		(Z) long 0.001mm, (X) cross 0.001mm
Moving speed of post		(Z) long 8m/min, (X) cross 6m/min
Motor power		7.5KW
Machine size	(L/W/H) (mm)	2200/1520/1840
Package size		2300/1620/2140
Net weight		2200KGS

Standard configuration:

wireless key&mouse 1 set	diamond cutter 1 set inner
diamond cutter 1 set outer	special ordered soft jaws 1 set
high precision prob system 1 set	4 station tool which can adjust X stroke
automatic lubrication system	cooling system(standard)
full cover safety door	tool case
training videos	--

Rim Repair Samples

---
