US$260,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Core Components
PLC, Engine, Bearing, Gearbox, Motor, Pressure Ve
Transport Package
Wooden Case
Product Description
Product Description
Product Parameters
Model
| Diameter of welded tube(mm)
| Wall thickness of welded tube(mm)
| Speed of tube welding(m/min)
| Power of main motor(kw)
| High frequency power(kw)
|
ZG16
| 8-25
| 0.25-1.0
| 30-100
| 30
| 60
|
ZG25
| 8-32
| 0.35-1.3
| 30-100
| 45
| 100
|
ZG32
| 13-50.8
| 0.5-2.0
| 30-90
| 110
| 150
|
ZG50
| 20-63.5
| 0.6-2.5
| 30-90
| 160
| 200
|
ZG60
| 25-63.5
| 0.8-3.0
| 20-80
| 185
| 250
|
ZG76
| 25-80
| 1.2-4.0
| 20-70
| 200
| 300
|
ZG90
| 32-90
| 1.5-4.5
| 20-60
| 110x2
| 400
|
ZG115
| 38-115
| 2.0-5.0
| 20-60
| 160x2
| 400
|
ZG165
| 80-165
| 2.0-6.0
| 15-50
| 200x2
| 500
|
ZG219
| 90-219
| 3.0-8.0
| 15-50
| 250x2
| 600
|
ZG273
| 185-273
| 4.0-10.0
| 15-40
| 250x1 185x2
| 800
|
ZG300
| 165-355
| 4.0-12.0
| 15-30
| 250x2 200x2
| 1200
|
Production Process
UNCOILER
360°rotary hydraulic-pressure expanding tight,which insure steel coil feeding alternatively and make steel strip go into accumulator freely
ACCUMULATOR
Overview:it has two kinds of accumulator for optional.usually big line use horizontal type,and small line use vertical type.
Forming part
Mainly roughly mill-forming steel strip and controlling weld seam
Sizing part
Mainly fine shaping pipe after welding and controlling size accuracy
Turkey's head
mainly used for straightening of finished pipe roughly online
Cold saw cutting
This numerical control cold cutting flying saw, with internationally advanced performance and all servo control, is suitable for online moving high-speed cutting of
