Automatic HDPE Big Water Tank Hollow Blow Molding Machine with Ce Certificate

Product Description

5000L Two layer Blow Molding Machine,can produce 1500L-5000L water tanks.
1.Adopt Siemens PLC,Siemens Touch Screen and MOOG to make the operation easy.
2.Adopt progressive hydraulic system by ourselves,easy to control.
3.Adopt inverter to control the clamping system,saving a lot of energy.
4.The technology of DIe Head is the same with Germany.
5.Configuration:

PARISION CONTROL THINCKNESS CONTROL	MOOG	JAPAN
PLC	SEIMENS	GERMANY
TEMPERATURE CONTROL MODULE	SEIMENS	GERMANY
SERVO VALVE & SERVO TRANSDUCER	MIRAN	ITALY
INVERTER	SEIMENS	GERMANY
HYDRAULIC OIL SEAL	DZ	TAIWAN
INTERMEDIATE RELAY	OMRON	JAPAN
PNEUMATIC VALVE	AIRTECH	TAIWAN
HYDRAULIC PUMP & VALVE	YUKEN	JAPAN
PNEUMATIC SWITCH & CONTACTOR	SEIMENS	GERMANY
HYDRAULIC MOTOR & SCREW MOTOR	SEIMENS	GERMANY
REDUCER	GUOMAO	CHINA

6.Specification

No		specifications	5000 Liter
		Model No.	2 layers
		Processing material	HDPE/HMWHDPE
1	Extruders	Gear Box Type	Hard surface
		Extruder Drive Motor (Inner)	132KW
		Extruder Drive Motor (Outer )	132KW
		Heating Load	145KW
		Max Screw Speed	50RPM
2	Accumulator Die Head	Heating Load	100kw
		Parison Control Cylinder	∮650X40mm
		Die-Core size [ Min / Max]	∮800MM
		Inverter	Siemens
3	Moulding Clamping Unit	CLAMPING PLATEN SIZE	2500X2700mm
		MAX MOLD SIZE	2350X2800mm
		Mould Thickness	1500-2000
		Clamping Pull Bar	180mm
4	Stretching and Blowing Unit	Spreading stroke	400-1200mm
		Vertical stroke max.	300mm
5	Electrical Control Panel	Thickness controller	100 points Moog
		Main Operation Panel	Siemens
		Die Head Control Temperature Control	Siemens
6	Hydraulic System	Hydraulic Drive motor (Main)	55KW
		Hydraulic Drive Motor (Parison Control)	11kw
		Oil Tank Capacity	1500Lx2
7	Gripper	Gripped stroke	550mm
		Discharge Stroke	2400mm
8	Hopper Loader	Loader	800kg/H 2pcs
		Hopper	50kg 2pcs
9	Production rate	Productivity	4-5pcs/h
	Of 5000 ltr.	Product Weight	85-95kg
10	Delivery period		6 months
11	Weight of Machine		92Ton
	Size of Machine	[L x W x H ] (M)	15mx13mx8.5m
12	Total power		580KW
13	Average power Consumption		320KW

DELIVERY TIME
6 months after the down payment;
TRAINNING
The Buyer could dispatch their operators to the Seller's factory for training, including machine operation, maintenance & simple repairs;
Or against the requests of the Buyer, the Seller's technician could train the Buyer's operators in the Buyer's factory in the periods of installing & adjusting;
INSTALLATION & ADJUSTMENT
The Seller could dispatch an engineer against the requests of the Buyer to install and adjust the machines for one week(free of charge) in the Buyer's factory. After one week,if the Buyer still needs the training,$100 should be paid for the engineer.
The Buyer should make a reservation in advance before delivery of the machines;
The Buyer should pay for the engineer's food & board while installation in buyer's factory.And the Buyer should also pay for the air ticket for the engineer.
GUARANTEE
The guarantee time is one year after the machines normally works in the Buyer's factory, if only the problem is cause due to quality control or any reason by the Seller. We will supply replaced parts free of charge and our engineers will guide you how to solve the problems.
Any problem caused due to irregular operation or incorrect maintenance by the Buyer won't be listed in guarantee coverage.

---
