| US$1,000.00-10,000.00 | 1 Piece (MOQ) |
| Item | X6036B | X6036A/X6136A |
| Spindle taper | ISO50(H) | ISO50(H) |
| Distance from spindle to table | 0-400mm | 0-400mm |
| Spindle speeds | 60-1800r.p.m | 60-1800r.p.m(H) |
| Table size | 1250×360mm | 1250×360mm |
| Table travel(Horizontal/Cross/Vertical) | 1000/320/240mm | 600/320/400mm |
| Feeding range of longitudinal.cross travel | 22-555mm/min(8 steps) | 22-555nn/min(8steps) |
| X,Y-axis rapid feed speed | 1080mm/min | 1080mm/min |
| Z-axis rapid feed speed | 590mm/min | 590mm/min |
| Z-axis motor power | 1.1kw | 1.1kw |
| Max.weight of workpiece | 400kg | 400kg |
| T-slot number/Width/Distance | 3/18mm/80mm | 3/18mm/80mm |
| Horse power for main motor | 4kw | 4kw |
| Coolant pump power | 90W(25L) | 90W(25L) |
| X,Y axis driving motor | 750W | 750W |
| Overall dimension | 2220×1790×1880mm | 1850×1790×1880mm |
| Packing size | 1880×1900×2250mm | 1800×1900×2250mm |
| 2300×1900×2250mm | 2300×1900×2250mm | |
| N.W./G.W. | 2200/2300kg(4400/4600kg) | 2100/2200kg(4200/4400kg) |
