SUS 304/316L Three Dimension Mixer for Granule/ Powder Blending

Product Description

Product Description The material is added to the mixing tank through the feeding machine or the vacuum feeding system. The mixing barrel space is crossed and perpendicular to each other. The main and driven shafts connected by the Y-type universal joint support the mixing barrel to make the threedimensional space. The unique translation, inversion and inversion movements accelerate the flow and diffusion during the mixing process, and avoid the segregation and accumulation of the specific gravity of the material caused by the centrifugal force of the general mixer, so that the material can be reached in a short time.
The machine is composed of machine base, drive system, three-dimensional motion mechanism, mixing cylinder, frequency conversion speed control motor, feeding outlet outlet, electrical control system, etc., the mixing cylinder in direct contact with the material is made of high-quality stainless steel material, and the inner wall of the cylinder is precision polished
Features - The mixing cylinder of the machine moves in multiple directions, the material has no centrifugal force, no specific gravity segregation and stratification, accumulation phenomenon, each component can have a disparity in weight ratio, the mixing rate is more than 99.9%, is a variety of mixers in an ideal product.
- The cylinder charging rate is large, up to 90% (ordinary mixer is only 40%), high efficiency and short mixing time.

Applications This multi-directional motion mixer is a material mixer widely used in pharmaceutical , chemical , metallurgy , food , light industry , agriculture and other industries . The machine can mix powder or granules very evenly to achieve the best results after mixing .
Product Parameters

Model	SYH-5	SYH-20	SYH-50	SYH-100	SYH-200	SYH-400	SYH-600	SYH-800	SYH-1000	SYH-1500
Mixing Barrel Volume (L)	5	20	50	100	200	400	600	800	1000	1500
Mixing Loading Volume (L)	4	17	40	85	170	340	500	680	850	1270
Mixing Loading Weight (kg)	4	15	40	80	100	200	300	400	500	750
Spindle Rotation Speed (rpm)	3-20	3-20	3-20	3-15	3-15	3-15	3-10	3-10	3-10	3-8
Motor Power (kw)	0.37	0.55	1.1	1.5	2.2	4	5.5	7.5	7.5	711
Machine Weight (kg)	90	100	200	650	900	1350	1550	2500	2650	4500
Dimension(L×W×H) (mm)	900×700×650	900×700×650	900×700×650	900×700×650	900×700×650	900×700×650	900×700×650	900×700×650	900×700×650	900×700×650

Related Products
High Speed Mixer Trough Type Mixer Nauta Mixer
Company Profile
Changzhou General Equipment Technology Co., Ltd. is located in LiYang city, a famous scenic and tourist city in JiangSu Province. It is a high-tech equipment manufacturing enterprise . The company is located in the local High-tech Machinery Industrial Park, with very convenient transportation.

The company covers an area of 70,000 square meters, plant area of 50,000 square meters, nearly 100 employees. The company has high-end processing equipment & testing equipment; It has D1 and D2 pressure vessel design qualifications and A2 pressure vessel manufacturing qualifications.Our main products are including Jet Mill Micronizer, Mixer, Granulator and Dryer, Chemical Equipment: Reactor, Heat Exchanger, Column, Tank and Environmental Protection Equipment, etc .
We provide technology research and development, process design, equipment manufacturing, installation and commissioning, project contracting and other comprehensive services. Our products are quite widely applied in the industry of petrochemical industry, Pharmaceutical , Agricultural Chemistry, New Energy, thermal power, steel smelting, Environmental Protection and other Service.Our customers are from the domestic and overseas markets, product quality and fantastic service are deeply praised by customers and partners.
We adhere to the concept of "Scientific Management, Advanced Technology, Quality Priority & Win-Win Cooperation", pursue the enterprise purpose of "Market by Quality, Win customers by Reputation, and seek development by Science & Technology", carry forward the enterprise culture, deepen the enterprise management, enhance the enterprise image, actively create new high-quality products, to provide customers with the superior quality.
Sincerely welcome all customers to visit our company for guidance and cooperation, let's make a better future together.
