Xj1002 Xj Series Crawler Tractor, Triangular Crawler Tractor, Farm Tractors, Rotary Cultivator, Tiller, Paddy Mud Agitator

Product Description

FEATURES

This tractor adopts triangular crawler walking, steering wheel operating, diffrential controlling of 360° spin in place, hydraulic steering lift , operating smartly and comfortably;
High chassis ground clearance 440mm, wide guage 1300mm, very good trafficability in mud field;
Commonly used three-point Linkage, multi-functional match different farming Implements to finish rotary tilling, ridging, furrowing works etc;
The advantages are: low ground pressure, strong sag resistances protect soil effectively without damage to plow pan, high efficiency.

SPECIFICATIONS

ITEM		PARAMETER
Product		Crawler Tractor XJ1002
Overall Dimension Length×Width×Heights ( mm ):		3630 × 1870 × 2650
Weight (kg)		2950
Structure		Chassis Based
Engine	Engine Model	LR4A3LR23/0735
	Rated Power ( kw/hp )	73.5KW/102HP
	Engine Type	Water-Cooled, 4-Cylinder, DI-Injection, Vertical Diesel.
	Rated Rotation Speed (r/min)	2300
	Starting Method	Electrical Start
Driving System	Drive Wheel	2 Wheel Drived
	Transmission	4×(1+1)×2 shifts
	Steering Operation Control	Wheel Steering Mechanical
	Type of Brake	Wet Disc Brake
Traveling System	Rubber Track(mm):	400x90x54
	Gauge (mm)	1300
	Theoretical Operating Speed ( km/h )	0~16.47
	Minimum Ground Clearance (mm)	440
Working Implement	Hydraulic Hitch Type	Semi-partition Hydraulic Hitch
	Rear Mounted Implements Type	Three-point Linkage
	PTO Rotating Speed (r/min)	720/1000

PRODUCT DETAILS

PACKING AND SHIPPING

FIELD TESTING

PRODUCTION ENVIROMENT

---
