US$12,000.00
|
1 unit
(MOQ)
|
Basic Info.
Certification
ISO 9001:2000
Drill Hole Diameter
<100mm
Drill Hole Depth
100-150m
Rotation Speed
60 200 400 610 1100 R/Min
Transport Package
Naked Packing
Specification
2600*1100*1820 mm
Production Capacity
30units/Month
Product Description
MDT-150C Spindle Crawler type Drilling Rig Portable Water Well Drilling Rig
Portable Well Drilling Machine And Boring Machine For Sale Phillipine, Soil Investigation,Mining Purpose
MDT-150C drilling rig is a kind of multi-use portable engineering drill. It is mostly used for the engineering geological exploration and pile examination in railway,bridge,traffic,hydroelectricity or industrial and civil architecture. It can also used in minor diameter foundation piles drilling.
Technical Specification:
| Basic Parameters |
| Drilling depth | 150m |
| Drilling diameter | 300mm |
| Drill pipe diameter | 42mm |
| Gross weight of drilling machine(engine not included) | 500kg |
| Dimension (length ×width × height) | 2600*1100*1820 mm |
| Revolving Plate |
| Rotate speed | 60 200 400 610 1100 r/min |
| Maximum torque | 1800N*m |
| Driving travel | 450mm |
| Maximum Cylinder driving force | 20,000N |
| Maximum Cylinder lifting force | 30,000N |
| Lifter |
| Lifting capacity | 24,000N |
| Bobbin line speed (2 layers) | 0.20 0.72 1.26 2.8 m/s |
| Bobbin diameter | 140mm |
| Rope diameter | 11mm |
| Rope capacity | 26m |
| Drilling rig |
| Type | Steel pipe quadripod |
| Height | 6m |
| Drive motor |
| Type | Changzhou ZS1100 diesel engine |
| Rated power | 11.03KW |
| Tare weighr | 150kg |
>>
