| HENGQIANG CONTROL SYSTEM | MAIHONG CONTROL SYSTEM | RAYNENG CONTROL SYSTEM |
| The machine system can be customized according to your requirements. | The machine system can be customized according to your requirements. | The machine system can be customized according to your requirements. |
| CARRIAGE | NEEDLE BED | DYNAMIC STITCH |
| Linear velocity of the head can reach 1.6m/s.Each system is equipped with five functions as rib transfer, weaving, hangging head, non-weave and pin. In addition, it is secured by short-circuited electromagnetism, motor overcurrent. Locked-Rotor, etc... | Split design, insert part fits with the needle are made of imported steel through fine blanking and grinding, which reduces the wear and tear of the stitches, decreases the resistance of the stitches, and effectively improves the knitting efficiency | It supports multi-segment stitch control of patterns in one line, realizes the weaving of multiple fabrics with different densities in the same line, and further improves weaving efficiency and diversity of the weaving forms. |
| DISPLAY SCREEN WITH KEYBOARD | SERVO MOTOR | 16 YARN FEEDER |
| It adopts industry LCD display with graphic touch control, multi-color, all time monitoring function. The data of the knitting amount, time, speed, roller, stitch, yarn feeder, etc... | Using cani control, can achieve the rapid return and direction changing of the machine carriage, accurate positioning, smooth conmutation . | The 16 yarns can be used by any weaving system and can be switched at any position. According to different knitting speed the control program can automatically adjust the position. |
| AUTOMATIC RESET PROBE | POSITIVE YARN FEEDER | AUTOMATIC REFUELING |
| Automatic reset function, which ensures any deviation of the probe can be reset automatically regardless of the area. | Positive yarn providing, successfully reduce yarn resistance, increase knitting efficiency. | In order to make the machine work better, we have developed 24-hours intelligent system for automatic refueling. |
| Gauge | 3G,3.5G,5G,5/7G,7G,8G,9G,10G,12G,14G,16G,18G |
| Knitting width | 52,60,66,72,80,100inch |
| Knitting system | Double system Double carriage double system(optional) 2+2 |
| Knitting speed | Controlled by servo-motor with 32 sections optional, max speed reach 1.6m/s. |
| Knitting function | Knit, miss, tuck, transfer, pointel, intarsia, jacquard, apparent or hide shaping and other regular or irregular patterns. |
| Racking | Controlled by servo-motor racking within 2 inches and with fine adjusting function. |
| Stitch density | Controlled by stepping motor, 32 section stitch select-able adjustable scope supported by subdivision technology: 0-650, the stitch of the knitwear can be accurately controlled. |
| Dynamic stitch | Using high speed stepping motor, multi-stitch function can be achieved in one line. |
| Needle selection | Advanced encoder reading pin.8-stage selecting needle setup composed of special electromagnet is regarded as efficient full width jacquard needle selector.which can be installed or removed simply from the carriage and maintained easily. |
| Transfer system | Combined design, single or double cam system all can transfer together or separately. Also one cam do transfer , another cam system for knitting, which will achieve high production. |
| Sinker system | Controlled by stepping motor, adjustable to different knitwear, up to be various results of shaping and patterns. |
| Quickly turning | Intelligent switching braiding system improves machine weaving efficiency. |
| Take-down system | Infrared alarm,Computer programs instruction, stepper motor control,32-stagetension selection with an adjustable range between0-100. |
| Color-changing system | 2×8 yarn feeders on each side of 4 guide rails, shift able on any needle position. |
| Yarn feeder device | Accurately control the tension of the yarn and ensure the consistency of the whole woven piece quality. 3G-10G Adopts roller feeding device 12G-18G Adopts the yarn storage device |
| Protection system | The machine will automatically alarm if yarn-breaking, knots, floating yarn, rewind, end of knitting, fail of racking, needle breakage, error programming occur, also set up the safety auto-lock protect device. |
| Control system | 1. LCD industrial display, Can display various parameters, which can be adjustable during operation. 2. USB memory interface,System memory 2G. 3. Free design system is visual and easy to understand and software upgrade free of charge. 4. Support multi-language operation as Chinese and English, Spanish, Russian etc. |
| Refueling device | Automatic refueling: Control the refueling time and frequency by setting the time. The oil pump lubricate the jack and long jack needle on the needle bed automatically to reduce the wear of the machine and increase its service life. |
| Network function | Has network interface,enable remote-monitoring via network,and connecting with ERP system. |
| Power supply | Single-phase 220V/three-phase 380V,adopt advanced CMOS technology, having memorizing function at power shock stop. |
| Non waste yarn Comb device | Non waste yarn Comb device(Optional) |
| Volume and weight | 3000*1000*1800mm,1150kgs(52inch) |
